X8SAX
by Supermicro
ATX - 1 x Processor Support - 24 GB DDR3 SDRAM Maximum RAM - 1.33 GHz) Memory Speed Supported - 6 x Memory Slots - Floppy Controller, Serial ATA/300 RAID Supported Controller - 7.1 Audio Channels - Gigabit Ethernet - 1 x PCI Express x4 Slots - 2 x PCI Express x16 Slots - 8 x USB Ports - S/PDIF - Onboard S/PDIF Header - 6 x SATA Interfaces
- Unspsc:
- 43201513
- Upc:
- 672042037056
- Description:
- X8SAX Desktop Board is designed with the utmost attention to detail to provide you with the highest standards in quality and performance. Built upon the functionality and the capability of the Intel X58 Express chipset, the X8SAX motherboard provides the performance and feature set required for dual-processor systems with configuration options optimized for intensive application and high-end workstation platforms.
Audio
- Audio Channels
- 7.1
- Sound Controller Manufacturer
- Realtek
- Sound Controller Model
- ALC883
General Information
- Brand Name
- Supermicro
- Manufacturer
- Supermicro Computer, Inc
- Manufacturer Part Number
- X8SAX
- Manufacturer Website Address
- http://www.supermicro.com
- Product Model
- X8SAX
- Product Name
- X8SAX Desktop Motherboard
- Product Type
- Desktop Motherboard
I/O Controller
- Controller Type
- Serial ATA/300
- RAID Levels
- 5
- RAID Supported
- Yes
I/O Expansions
- Number of PCI Express x16 Slots
- 2
- Number of PCI Express x4 Slots
- 1
- Number of PCI Slots
- 1
- Number of PCI-X Slots
- 2
- Number of Total Expansion Slots
- 6
- Total Number of PCI Express Slots
- 3
Interfaces/Ports
- Audio Line In
- Yes
- Audio Line Out
- Yes
- Microphone Port
- Yes
- Network (RJ-45)
- Yes
- Number of PS/2 Ports
- 2
- Number of S/PDIF Out Ports
- 1
- Number of USB 2.0 Ports
- 8
- PS/2 Port
- Yes
- S/PDIF
- Yes
- Total Number of USB Ports
- 8
Memory
- Maximum Memory
- 24 GB
- Memory Speed Supported
- 800 MHz
- Memory Standard
- DDR3-800/PC3-6400
- Memory Technology
- DDR3 SDRAM
- Number of Memory Slots
- 6
Miscellaneous
- Additional Information
- System BIOS:BIOS Type:4Mb SPI Flash EEPROM with AMI BIOSBIOS Features:DMI 2.3PCI 2.2ACPI 1.0 / 2.0USB Keyboard supportSMBIOS 2.3
- Green Compliance Certificate/Authority
- RoHS
- Green Compliant
- Yes
- Package Contents
- X8SAX Desktop Board1 x Motherboard Manual1 x ATX Floppy Cable6 x 2ft. Amphenol, SATA Cable1 x Internal to External Cable for 1394 Connector1 x CD1 x Motherboard I/O Shield
Network & Communication
- Gigabit Ethernet
- Yes
Onboard Interfaces
- Number of SATA Interfaces
- 6
- Onboard Audio Header
- Yes
- Onboard LEDs Header
- Yes
- Onboard S/PDIF Header
- Yes
- Total Number of Onboard USB Ports
- 3
Physical Characteristics
- Depth
- 10"
- Form Factor
- ATX
- Width
- 12"
Processor & Chipset
- 64-bit Processing
- Yes
- Chipset Manufacturer
- Intel
- Chipset Model
- X58 Express
- Processor Socket
- Socket B LGA-1366
- Processor Supported
- Core i7 Extreme Edition
- Processor Technology
- Enhanced SpeedStep Technology
- QuickPath Interconnect
- 6.40 GT/s
- Total Processor Supported
- 1
