Conditions Available
Warranties Available
X99-A
by Asus
ATX - 1 x Processor Support - 64 GB DDR4 SDRAM Maximum RAM - 3.20 GHz (O.C.) Memory Speed Supported - 8 x Memory Slots - SLI, CrossFireX Support - Serial ATA/600 RAID Supported Controller - 6 x USB 3.0 Port - 7.1 Audio Channels - Gigabit Ethernet - 2 x PCI Express x1 Slots - 4 x PCI Express x16 Slots - 10 x USB Ports - S/PDIF - 1 x SATA Express Interfaces - Onboard S/PDIF Header - 8 x SATA Interfaces
- Unspsc:
- 43201513
- Upc:
- 889349699133
- Description:
- Intel® Core™ i7 Processor LGA2011-v3 ReadyThis motherboard supports Intel® Core™ i7 processors in the LGA2011-v3 package, with memory and PCI Express controllers integrated to support 4-channel (8 DIMM) DDR4 memory and 40/28 PCI Express 3.0/2.0 lanes.Intel® X99 Express ChipsetThe Intel® X99 Express Chipset is a single-chipset design that supports socket LGA2011-v3 Intel® Core™ i7 processors. It provides improved performance by utilizing serial point-to-point links, allowing increased bandwidth and stability. Additionally, X99 provides a maximum 6 USB 3.0 ports, 10 SATA 6Gbit/s ports for faster data retrieval.
Audio
- Sound Controller Manufacturer
- Realtek
- Sound Controller Model
- ALC1150
- Audio Channels
- 7.1
Controls/Indicators
- Buttons & Keys
- EZ XMP
Interfaces/Ports
- S/PDIF
- Yes
- Number of Network (RJ-45) Ports
- 1
- Network (RJ-45)
- Yes
- Audio Line In
- Yes
- Audio Line Out
- Yes
- Microphone Port
- Yes
- Total Number of USB Ports
- 10
- Number of USB 2.0 Ports
- 4
- Number of USB 3.0 Ports
- 6
- Number of S/PDIF Out Ports
- 1
- PS/2 Port
- Yes
- Number of PS/2 Ports
- 1
General Information
- Product Type
- Desktop Motherboard
- Manufacturer Part Number
- X99-A
- Manufacturer Website Address
- http://usa.asus.com
- Manufacturer
- ASUS Computer International
- Product Model
- X99-A
- Product Name
- X99-A Rev. 1.01 Desktop Motherboard
- Product Series
- X99-A
- Brand Name
- Asus
I/O Expansions
- Number of PCI Express x1 Slots
- 2
- Number of Total Expansion Slots
- 6
- Number of PCI Express x16 Slots
- 4
- PCI Express Standard
- PCI Express 2.0
- Total Number of PCI Express Slots
- 6
Memory
- Maximum Memory
- 64 GB
- Memory Technology
- DDR4 SDRAM
- Memory Standard
- DDR4-2133/PC4-17000
- Number of Memory Slots
- 8
- Memory Form Factor
- DIMM
- Memory Speed Supported
- 2.13 GHz
Miscellaneous
- Package Contents
- X99-A Rev. 1.01 Desktop MotherboardUser's ManualQ-Shield4 x SATA 6Gb/s Cables1 x SLI Bridge1 x Q-connector (2 in 1)
- Certifications & Standards
- KCCEC-TickBSMIFCC
- Country of Origin
- China
- Green Compliant
- Yes
- Green Compliance Certificate/Authority
- RoHS
Network & Communication
- Gigabit Ethernet
- Yes
Physical Characteristics
- Form Factor
- ATX
- Width
- 12"
- Depth
- 9.6"
Power Description
- Power Supply Supported
- EATX12V
Processor & Chipset
- Processor Supported
- Xeon
- Total Processor Supported
- 1
- Processor Socket
- Socket LGA 2011-v3
- Processor Technology
- Smart Response Technology
- 64-bit Processing
- Yes
- Chipset Manufacturer
- Intel
- Chipset Model
- X99
- Multi GPU Supported
- CrossFireX
Video
- Onboard Video
- No
I/O Controller
- RAID Levels
- 10
- Controller Type
- Serial ATA/600
- RAID Supported
- Yes
Onboard Interfaces
- Number of SATA Interfaces
- 8
- Total Number of Onboard USB Ports
- 8
- Number of Onboard USB 2.0 Ports
- 4
- Number of Onboard USB 3.0 Ports
- 4
- Onboard S/PDIF Header
- Yes
- Onboard Serial Header
- Yes
- Number of SATA Express Interfaces
- 1
- Onboard Thunderbolt Header
- Yes
