X8DTN+
by Supermicro
Extended ATX - 2 x Processor Support - 144 GB DDR3 SDRAM Maximum RAM - 1.33 GHz) Memory Speed Supported - 18 x Memory Slots - Floppy Controller, Serial ATA/300, Ultra ATA/100 (ATA-6) RAID Supported Controller - On-board Video Chipset - ATI ES1000 - Gigabit Ethernet - 1 x PCI Express x4 Slots - 2 x PCI Express x8 Slots - 2 x USB Ports - VGA - 6 x SATA Interfaces


Unspsc:
43201513
Upc:
672042060917
Description:
This X8DTN+ Server Board is designed with the utmost attention to detail to provide you with the highest standards in quality and performance. The X8DTN+ supports the Intel 5500 Series Processors, the first dual-processing platform that offers Intel Quick Path Interconnect (QPI) Technology to provide the next generation point-to-point system interface, replacing the current Front Side Bus.
General Information
Brand Name
Supermicro
Manufacturer
Supermicro Computer, Inc
Manufacturer Part Number
X8DTN+
Manufacturer Website Address
http://www.supermicro.com
Product Model
X8DTN+
Product Name
X8DTN+ Server Motherboard
Product Type
Server Motherboard
I/O Controller
Controller Type
Ultra ATA/100 (ATA-6)
RAID Levels
5
RAID Supported
Yes
I/O Expansions
Number of PCI Express x4 Slots
1
Number of PCI Express x8 Slots
2
Number of PCI-X Slots
3
Number of Total Expansion Slots
8
Total Number of PCI Express Slots
3
Interfaces/Ports
Network (RJ-45)
Yes
Number of PS/2 Ports
2
Number of USB 2.0 Ports
2
PS/2 Port
Yes
Serial Port
Yes
Total Number of USB Ports
2
VGA
Yes
Memory
Maximum Memory
144 GB
Memory Speed Supported
800 MHz
Memory Standard
DDR3-800/PC3-6400
Memory Technology
DDR3 SDRAM
Number of Memory Slots
18
Miscellaneous
Additional Information
System BIOS:32Mb SPI Flash EEPROM with AMI BIOSPlug and Play (PnP)PCI 2.2ACPI Up to 3.0USB Keyboard Support
Green Compliance Certificate/Authority
RoHS
Green Compliant
Yes
Network & Communication
Gigabit Ethernet
Yes
Onboard Interfaces
Number of IDE Interfaces
1
Number of SATA Interfaces
6
Onboard LEDs Header
Yes
Total Number of Onboard USB Ports
2
Physical Characteristics
Depth
13"
Form Factor
Extended ATX
Width
13.7"
Processor & Chipset
64-bit Processing
Yes
Chipset Manufacturer
Intel
Chipset Model
5520
Processor Socket
Socket B LGA-1366
Processor Supported
Xeon Quad-core
Processor Technology
Enhanced SpeedStep Technology
QuickPath Interconnect
6.40 GT/s
Total Processor Supported
2
Video
Graphics Controller Manufacturer
ATI
Graphics Controller Memory
32 MB
Graphics Controller Model
ES1000
Onboard Video
On-board Video Chipset
