XR2
by Ubiquiti Networks
Mini PCI - Type IIIa - 54 Mbit/s - 2.46 GHz ISM - 656.2 ft Indoor Range - 31.1 Mile Outdoor Range - Internal
- Unspsc:
- 43201409
- Nsn:
- 3010009650064
- Description:
- The XtremeRange series of radio modules by Ubiquiti leverages our strong knowledge and experience gained from customer interactions, field performance evaluations, and lab research; and improves upon the original and highly successful SuperRange series of high-performance 802.11 radio cards. The XtremeRange2 is a carrier-class 802.11b/g based 2.4GHz radio module specifically designed for mesh, bridging, and infrastructureapplications requiring the high levels of performance and reliability.
Interfaces/Ports
- Host Interface
- Mini PCI - Type IIIa
General Information
- Product Type
- Wi-Fi Adapter
- Manufacturer Part Number
- XR2
- Manufacturer Website Address
- http://www.ubnt.com
- Manufacturer
- Ubiquiti Networks, Inc
- Product Model
- XR2
- Product Name
- Carrier-Class 2.4GHz 802.11b/g Radio Module
- Product Line
- XtremeRange
- Brand Name
- Ubiquiti
Miscellaneous
- Certifications & Standards
- FCCCEIEEE Standards:802.11b802.11g802.1x
- System Requirements
- Operating Systems:LinuxWindows XPWindows 2000
- Green Compliant
- Yes
- Green Compliance Certificate/Authority
- RoHS
Physical Characteristics
- Form Factor
- Internal
Technical Information
- Wireless Security
- WPAWPA2AES-CCMTKIPIEEE 802.1xWEP 64/128/152-bit
- Wireless Transmission Speed
- 54 Mbit/s
- Wireless LAN Standard
- IEEE 802.11b/g
- ISM Band
- Yes
- UNII Band
- No
- Indoor Antenna Range
- 656.2 ft
- Outdoor Antenna Range
- 31.1 Mile
- ISM Minimum Frequency
- 2.41 GHz
- ISM Maximum Frequency
- 2.46 GHz
- Number of Antennas
- 1
- Antenna Connector
- MMCX Connector
