X8DTH-6F
by Supermicro
Extended ATX - 2 x Processor Support - 96 GB DDR3 SDRAM Maximum RAM - 1.33 GHz) Memory Speed Supported - 12 x Memory Slots - Serial Attached SCSI (SAS), Serial ATA/300 RAID Supported Controller - On-board Video Chipset - Matrox G200eW - Gigabit Ethernet - 7 x PCI Express x8 Slots - 4 x USB Ports - VGA - 6 x SATA Interfaces
- Unspsc:
- 43201513
- Upc:
- 672042042692
- Description:
- This X8DTH-6F Server Board is designed with the utmost attention to detail to provide the highest standards in quality and performance. X8DTH-6F Server Board supports the Intel 5500 Series Processor, the first dual-processor platform that supports the Intel QuickPath Interconnect (QPI) Technology, providing the next generation point-to-point system interface to replace the current Front Side Bus.
Interfaces/Ports
- VGA
- Yes
- Network (RJ-45)
- Yes
- Serial Port
- Yes
- Total Number of USB Ports
- 4
- Number of USB 2.0 Ports
- 4
- PS/2 Port
- Yes
- Number of PS/2 Ports
- 2
General Information
- Product Type
- Server Motherboard
- Manufacturer Part Number
- X8DTH-6F
- Manufacturer Website Address
- http://www.supermicro.com
- Manufacturer
- Supermicro Computer, Inc
- Product Model
- X8DTH-6F
- Product Name
- X8DTH-6F Server Motherboard
- Brand Name
- Supermicro
I/O Expansions
- Number of Total Expansion Slots
- 8
- Number of PCI Express x8 Slots
- 7
- Total Number of PCI Express Slots
- 7
Memory
- Maximum Memory
- 96 GB
- Memory Technology
- DDR3 SDRAM
- Memory Standard
- DDR3-800/PC3-6400
- Number of Memory Slots
- 12
- Memory Speed Supported
- 800 MHz
Miscellaneous
- Additional Information
- System BIOS:32Mb SPI Flash EEPROM with AMI BIOSPlug and Play (PnP)PCI 2.2ACPI up to 3.0USB Keyboard Support
- Green Compliant
- Yes
- Green Compliance Certificate/Authority
- RoHS
Network & Communication
- Gigabit Ethernet
- Yes
Physical Characteristics
- Form Factor
- Extended ATX
- Width
- 12"
- Depth
- 13"
Processor & Chipset
- Processor Supported
- Xeon Quad-core
- Total Processor Supported
- 2
- Processor Socket
- Socket B LGA-1366
- Processor Technology
- Enhanced SpeedStep Technology
- 64-bit Processing
- Yes
- Chipset Manufacturer
- Intel
- Chipset Model
- 5520
- QuickPath Interconnect
- 6.40 GT/s
Video
- Graphics Controller Manufacturer
- Matrox
- Graphics Controller Model
- G200eW
- Onboard Video
- On-board Video Chipset
I/O Controller
- RAID Levels
- 1+0
- Controller Type
- Serial ATA/300
- RAID Supported
- Yes
Onboard Interfaces
- Number of SATA Interfaces
- 6
- Number of SAS Interfaces
- 8
- Total Number of Onboard USB Ports
- 4
- Onboard LEDs Header
- Yes
