S5000PAL
by Intel
2 x Processor Support - 32 GB DDR2 SDRAM Maximum RAM - 667 MHz) Memory Speed Supported - 8 x Memory Slots - Floppy Controller, Serial ATA/300, Ultra ATA/100 (ATA-6) - On-board Video Chipset - ATI ES1000 - Gigabit Ethernet - 2 x USB Ports - VGA - 6 x SATA Interfaces
- Unspsc:
- 43201513
- Upc:
- 585818310904
- Description:
- The Intel Server Board S5000PAL supports Dual-Core Intel Xeon processors using the Intel 5000P chipset, it delivers high levels of performance, reliability and manageability. Together, these capabilities address the needs of enterprise-level computing in space-constrained environments, particularly those running Internet, departmental database, data-center, and other high-transaction applications.
Interfaces/Ports
- VGA
- Yes
- Network (RJ-45)
- Yes
- Serial Port
- Yes
- Total Number of USB Ports
- 2
- Number of USB 2.0 Ports
- 2
General Information
- Product Type
- Server Motherboard
- Manufacturer Part Number
- S5000PAL
- Manufacturer Website Address
- http://www.intel.com
- Manufacturer
- Intel Corporation
- Product Model
- S5000PAL
- Product Name
- S5000PAL Server Motherboard
- Brand Name
- Intel
I/O Expansions
- Number of Total Expansion Slots
- 1
Memory
- Maximum Memory
- 32 GB
- Memory Technology
- DDR2 SDRAM
- Memory Standard
- DDR2-533/PC2-4200
- Number of Memory Slots
- 8
- Memory Form Factor
- DIMM
- Memory Speed Supported
- 533 MHz
Miscellaneous
- Additional Information
- Slots:Riser card slot that supports full-height and full-length add in cards. This slot uses Intel Adaptive Slot Techonolgy to route both PCI-X and PCI-Express signals, so cards of either type can be usedA secondary riser slot which supports up to two low-profile PCI Express add-in cards on x4 lane widthsIntegrated Management Type:IPMI 2.0-compliant onboard platform instrumentationIntel System Management Software 1.0Support for Intel Remote Management ModuleSupport for Intel Local Control Panel
Network & Communication
- Gigabit Ethernet
- Yes
Physical Characteristics
- Width
- 12"
- Depth
- 13"
Processor & Chipset
- Processor Supported
- Xeon
- Total Processor Supported
- 2
- Processor Socket
- Socket J LGA-771
- Processor Technology
- Hyper-Threading Technology
- Front Side Bus
- 667 MHz
- 64-bit Processing
- Yes
- Chipset Manufacturer
- Intel
- Chipset Model
- 5000P
Video
- Graphics Controller Manufacturer
- ATI
- Graphics Controller Model
- ES1000
- Graphics Controller Memory
- 16 MB
- Onboard Video
- On-board Video Chipset
I/O Controller
- Controller Type
- Ultra ATA/100 (ATA-6)
Onboard Interfaces
- Number of IDE Interfaces
- 1
- Number of SATA Interfaces
- 6
- Total Number of Onboard USB Ports
- 2
- Onboard LEDs Header
- Yes
