Conditions Available
Warranties Available
SU3000RTXLCD2U
by Tripplite
3000 VA/2700 W - 4.10 Minute - 2U Tower/Rack Mountable - 4.10 Minute - 4 x NEMA 5-15R - , 4 x NEMA 5-15/20R - , 1 x NEMA L5-30R - Over Voltage, Under Voltage, Brownout
- Unspsc:
- 39121011
- Description:
- Tripp Lite Smart Online UPS systems offer high performance power protection ideal for critical server and network equipment in datacenters, computer rooms and network closets. Online, double-conversion Uninterruptible Power Supply (UPS) maintains perfectly regulated output power by continuously converting raw AC input to DC, then re-converting output back to AC. Fully regulated sine wave AC output with +/-2% voltage regulation powers network equipment continuously, even during severe brownouts and overvoltages, all without depleting UPS battery reserves. Maintains battery-derived AC output during power failures with zero transfer time. Extended runtime options available. Interactive LCD interface reports UPS operating mode, detailed UPS and site-power data, plus enables a variety of UPS setup and configuration options. Up to 99% efficiency with economy mode option saves BTU heat output and energy costs. Network management interfaces support communications via USB, RS-232, contact-closure and optional SNMPWEBCARD network interface. Built-in DB9 port offers both enhanced RS-232 data and basic contact closure monitoring ability. HID-compliant USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X. Includes PowerAlert monitoring software and complete cabling. Emergency Power Off (EPO) interface. LED display reports UPS operating mode, line power availability, battery mode operation, inverter operation, ECO mode status and output power availability. Audible alarm with push-button momentary alarm-cancel and silent-mode LCD configuration options. Frequency regulation and conversion options for all 50/60Hz applications. Programmable self-test. Battery independent restart. Fault-tolerant auto-bypass mode. Field-replaceable, hot-swappable internal batteries and external battery packs.
Battery Information
- Battery Life
- 6 Year
- Battery Chemistry
- Sealed Lead Acid
- Hot Swappable
- Yes
- Maximum Battery Recharge Time
- 3 Hour
- Backup/Run Time (Half Load)
- 11.30 Minute
- Backup/Run Time (Full Load)
- 4.10 Minute
Controls/Indicators
- Status Indicators
- 7 Front Panel Leds Indicate Line Power Availability AC to DC Conversion Battery Mode Operation Inverter Mode Eco Mode Operation Bypass Mode Operation AC Output Status
Interfaces/Ports
- USB
- Yes
- Serial Port
- Yes
Environmental Conditions
- Sound Emission
- 50 dB(A)
- Temperature
- 104°F (40°C)
- Thermal Dissipation
- 801 BTU/h
General Information
- Product Type
- Dual Conversion Online UPS
- Manufacturer Part Number
- SU3000RTXLCD2U
- Manufacturer Website Address
- http://www.tripplite.com
- Manufacturer
- Tripp Lite
- Product Model
- SU3000RTXLCD2U
- Product Name
- SmartOnline SU3000RTXLCD2U 3000VA Tower/Rack Mountable UPS
- Product Line
- SmartOnline
- Brand Name
- Tripp Lite
Management
- Network Management
- SNMP Manageable
- Alarm
- Remote Shutdown
Miscellaneous
- Package Contents
- SmartOnline SU3000RTXLCD2U 3000VA Tower/Rack Mountable UPS PowerAlert UPS Monitoring Software CD USB Cable DB9 Cable
- Software Included
- PowerAlert UPS Monitoring Software
- Certifications & Standards
- UL1778 CSA FCC Part 15 Category A (EMI)
- Green Compliant
- Yes
- Green Compliance Certificate/Authority
- RoHS
Physical Characteristics
- Weight (Approximate)
- 70.50 lb
- Form Factor
- Tower/Rack Mountable
- Rack Height
- 2U
- Height
- 3.4"
- Width
- 17.3"
- Depth
- 25.5"
Power Description
- Circuit Breaker
- Yes
- Input Voltage
- 127 V AC
- Output Voltage
- 127 V AC
- Surge Energy Rating
- 570 J
- Waveform Type
- Pure Sine Wave
- Load Capacity (VA)
- 3000 VA
- Load Capacity (Watt)
- 2700 W
Technical Information
- Emergency Power OFF
- Yes
- Protection Type
- Brownout
- Receptacles
- 1 x NEMA L5-30R
- Plug/Connector Type
- NEMA L5-30P
- Cord Length
- 10 ft
