Tripplite 12 X Iec 320 C13 2 X Iec 320 C19 16 1u 19
Recycle
Conditions Available
Lock
Warranties Available

PDU12IEC
by Tripplite
12 x IEC 320-C13, 2 x IEC 320-C19 - 16 - 1U 19" Rack-mountable


Unspsc:
39121017
Description:
Tripp Lite's PDU12IEC AC power distribution unit offers 16 amp capacity in a versatile 100-240 volt, worldwide compatible, multi-mount cabinet. Detachable mounting flanges are configurable for wallmount, under-counter or 1U/0U rackmount installation. Uses only 1 rack space (1U) when installed in any 19 inch rack, with the potential for 0U mounting in the cable management area of most rack enclosures. Detachable flanges with pre-punched access holes and adjustable depth channels allow user configuration in dozens of potential mounting schemes. Attractive housing with 14 outlets measuring only 4.25 inches in depth. Unfiltered electrical pass-through without a power switch makes PDU12IEC ideal for distributing alternate waveform UPS or generator power in rack enclosures, network closets and more. Includes 12 IEC320 C13 and 2 IEC320 C19 outlets, IEC320 C20 inlet connector (user supplies appropriate input cable), set of 16 amp circuit breakers, grounding lug and rugged all-metal case design.
General Information
Product Type
PDU
Manufacturer Part Number
PDU12IEC
Manufacturer Website Address
http://www.tripplite.com
Manufacturer
Tripp Lite
Product Model
PDU12IEC
Product Name
PDU12IEC PDU Basic 100V - 240V 16A 14 Outlet
Brand Name
Tripp Lite
Miscellaneous
Additional Information
Corded AC power distribution unit with 16 amp capacity in a versatile 100-240 volt, worldwide compatible, multi-mount cabinetVersatile all-metal cabinet with detachable mounting flanges allows wallmount, under-counter and 19 inch rackmount mounting in both 1U or 0U formatsDetachable flanges with pre-punched access holes and adjustable depth channels allow user configuration in dozens of potential mounting schemes, including zero-U rackmount capability in the cable management area or other available space within a rack enclosureUnfiltered electrical pass-through reliably distributes alternate waveform AC power from UPS or generator to supported equipmentAttractive all-metal housing receptacles measures only 4.25 in. in depth12 IEC320 C13 and 2 IEC320 C19 output receptacles accept common IEC320 C14 and C20 equipment plugsIEC320 C20 inlet connection supports a variety of appropriate user-supplied input cordsSwitch-free design prevents the potential for accidental shutoff of connected loads16 amp total electrical capacity with seperate 16A circuit breakers100-240V AC, 50/60Hz electrical compatibility
Package Contents
PDU12IEC PDU Basic 100V - 240V 16A 14 OutletWarranty informationInstruction manual
Compatibility
TYPICAL APPLICATIONS: Multi-outlet power distribution unit is the ideal means of powering multiple loads in 19 inch rackmount, wallmount and under-counter applications: internetworking, PC systems, telecommunications, audio/video, security, sound reinforcement and more. Ideal for distribution of UPS, generator or commercially derived AC power to protected equipment.
Certifications & Standards
cUL, UR
Physical Characteristics
Form Factor
Rack-mountable
Rack Height
1U
Power Description
Input Voltage
240 V AC
Output Voltage
240 V AC
Power Rating
16
Technical Information
Input Receptacles
IEC 320-C20
Output Receptacles
2 x IEC 320-C19
