SMART1200XLHG
by Tripplite
1000VA/750W - 16 Minute Full Load - 4 x NEMA 5-15R

Unspsc:: 39121011
Upc:: 37332116406
Description:: Tripp Lite's SMART 1200XLHG offers medical-grade UPS protection with built-in line-interactive voltage regulation, expandable battery runtime and intelligent monitoring with unattended shutdown capability. UL 60601-1 listed as medical electrical equipment. Built-in isolation transformer with Faraday shield offers full line isolation and removes common mode noise while maintaining full AC surge suppression in all modes. Includes high quality hospital-grade plug and outlets. Resistant to electrostatic discharge. 1000VA power handling capacity supports computers, inter-networking equipment and other critical loads during commercial power failures. External battery connector allows configuration for up to several hours of runtime during power failures by adding one or more external battery packs (BP36V15-2U limit 1 or BP36V42-3U multi-pack compatible). Line interactive voltage regulation corrects brownouts as low as 81V and overvoltages as high as 143V back to normal 120V levels, saving battery reserves for use only during complete power failures. Includes diagnostic LEDs and 2 built-in communications ports (1 USB, 1 DB9) that work with included PowerAlert Software and cabling to provide automatic unattended shutdown of connected network and PC applications.

Request A Quote

Technical Specifications
Similar Products

Battery Information

Battery Life: 6 Year

Battery Chemistry: Sealed Lead Acid

Hot Swappable: Yes

Maximum Battery Recharge Time: 4 Hour

Backup/Run Time (Half Load): 34 Minute

Backup/Run Time (Full Load): 16 Minute

Controls/Indicators

Status Indicators: Includes 5 front-panel indicator LEDs to show battery charge level, AC line voltage levels, automatic voltage regulation status, UPS load level and replace battery warning

Interfaces/Ports

USB: Yes

Environmental Conditions

Temperature: 104°F (40°C)

General Information

Product Type: Line-interactive UPS

Manufacturer Part Number: SMART1200XLHG

Manufacturer Website Address: http://www.tripplite.com

Manufacturer: Tripp Lite

Product Name: SmartPro 1200XLHG UPS

Product Line: SmartPro

Brand Name: Tripp Lite

Management

Network Management: SNMP Manageable

Alarm: Low Battery

Miscellaneous

Additional Information: Ideal UPS protection for applications in medical patient-care areas where UL 2601-1 listed medical electrical equipment is requiredMaintains less than 300 microamps leakage current for UPS and all connected equipmentBuilt-in isolation transformer with faraday shield offers full isolation and removes common mode noise while maintaining full AC surge suppression in all modesProvides connected equipment with continuous power during short and long duration loss of commercial powerExpandable runtime is available with the addition of one or more external battery packs (part# BP36V27)Line-interactive voltage regulation corrects brownouts and overvoltages from 81 to 143 volts back to usable 120V output levels, without using battery powerHospital-grade plug and outlets offer added degree of safety and reliability to input/output connectionsFull line isolation prevents shock potential and operational problems in sensitive electronic equipmentResistant to electrostatic dischargeSupports loads up to 1000VA / 750 watts34 minutes half load runtime (500VA/375 watts), 16 minutes full load runtime (1000VA/750 watts)4 protected hospital-grade outlets; 6-ft. cord1-RS-232 and 1-USB serial port for network interface; SNMP compatibleSNMP compatible with separate purchase SNMPWEBSOLO ethernet adapter accessoryComplete surge protection, line isolation and EMI/RFI noise filtering2 year product warrantyPowerAlert unattended shutdown software and complete cabling included5 diagnostic LEDs indicate AC present, on battery, voltage correction, overload & battery low/replaceBattery replacement doorBack panel grounding lug

Package Contents: SmartPro 1200XLHG UPSSMART 1200XLHG Medical Grade Tower UPS SystemPowerAlert Software and cablingWarranty informationInstruction manual

Certifications & Standards: UL1778 (USA, Series AGSM1200PSR3HG), UL2601-1 (Medical), cUL (Canada), FCC Class A (emissions), Conforms to IEEE 587 / ANSI C62.41 specifications
