Conditions Available
Warranties Available
IC232485S
by Startech
2 x Serial Port - Wall Mountable
- Unspsc:
- 43222625
- Upc:
- 114547964098
- Description:
- The IC232485S Industrial RS232 to RS-422/485 Serial Converter is a bi-directional adapter that lets you adapt an RS232 data signal to either RS485 (2 or 4-wire) or RS422 and vice-versa, with support for baud rates up to 921.6 Kbps. Ideal for industrial environments, the serial port converter provides 15KV ESD protection on all signal pins to protect costly and often sensitive control equipment against electrical damage. The serial converter also features a sturdy wall-mountable metal housing with Power, Tx and Rx LED indicators for simple status monitoring. The adapter supports auto baud rate detection as well as RS-422 and RS485 mode detection, with an integrated dip switch for manual mode selection if needed, and supports connection distances of up to 4000ft (1200m). Backed by a 2-year StarTech.com warranty and free lifetime technical support.
Interfaces/Ports
- USB
- No
- Network (RJ-45)
- No
- Serial Port
- Yes
- Parallel Port
- No
- Network (RJ-11)
- No
- Phone Line (RJ-11)
- No
- Number of Serial Ports
- 2
- PoE (RJ-45) Port
- No
- Centronics Port
- No
General Information
- Product Type
- Device Server
- Manufacturer Part Number
- IC232485S
- Manufacturer Website Address
- http://www.startech.com
- Packaged Quantity
- 1
- Manufacturer
- StarTech.com
- Product Name
- Industrial RS232 to RS422/485 Serial Port Converter with 15KV ESD Protection
- Brand Name
- StarTech.com
Miscellaneous
- Package Contents
- Industrial RS232 to RS422/485 Serial Port Converter with 15KV ESD Protection Power Adapter 1 x Universal Power Adapter (NA/EU/UK) 1 x Instruction Manual
- Certifications & Standards
- CE FCC
- Green Compliant
- Yes
- Green Compliance Certificate/Authority
- RoHS
Physical Characteristics
- Weight (Approximate)
- 5.30 oz
- Color
- Black
- Form Factor
- Wall Mountable
- Height
- 0.9"
- Width
- 2.3"
- Depth
- 4.6"
Power Description
- Input Voltage
- 5 V DC
Wireless Specifications
- Wireless LAN
- No
- ISM Band
- No
- UNII Band
- No
DIGIINTL 70002405
Digi International Digi ConnectPort LTS 16 MEI, 10/100/1000Base-T(X), 100 - 240 V, 800 mA, TCP/UDP, DHCP, telnet, ReverseTelnet/SSHv2/SSL, IPv4/IPv6, SSH, SSL/TLS, Windows Server 2003
LANTRONIX slc80161201s
