AL2012E39
by Nortel

---

24 x 10/100Base-TX

Number of Network (RJ-45) Ports

24

Management Port

Yes

Total Number of Network Ports

24

Port/Expansion Slot Details

1 x Gigabit Ethernet Expansion Slot

Product Type

Ethernet Switch

Manufacturer Part Number

AL2012E39

Manufacturer Website Address

http://www.nortelnetworks.com

Manufacturer

Nortel Networks Limited

Product Model

420-24T

Product Name

BayStack 420-24T Ethernet Switch

Product Line

BayStack

Brand Name

Nortel

Expansion Slot Type

SFP

Number of Total Expansion Slots

1

Number of SFP Slots

1

Network Technology

10/100Base-TX

Ethernet Technology

Fast Ethernet

Media Type Supported

Twisted Pair

Additional Information

Data Rate and Encoding:10 Mbps: Manchester encoding100 Mbps: 4B/5B encoding1000 Mbps: 8B/10BStackable 10/100/1000 layer 2 Ethernet switch provides 24 10BASE-T/100BASE-TX auto-sensing ports, 1 GBIC-based (Gigabit Interface Converter) uplink slot, and built-in stacking connectors.Full auto-sensing on every UTP port automatically detects and supports the speed and mode of a connected device-10 Mbps or 100 Mbps, half- or full-duplex.A "plug-and-play" stacking architecture enables up to 8 BayStack 420-24T Switches to be connected with stacking cables into a fail-safe cascade configuration that provides up to 192 ports, managed as a single entity.Wire-speed performance is achieved by a 12.8 Gigabit per second (Gbps) switching fabric and ASICs that support full 802.1D-compliant MAC Layer frame forwarding and filtering across all ports at up to 5.1 million packets per second.GBIC (Gigabit Interface Converter) module options provide a choice of fiber interfaces to connect to distant servers or a larger network, including SX, LX, XD (50 km) and ZX (70 km) for long haul connectivity.MultiLink Trunking (MLT) groups up to four 10/100 uplink ports together to provide up to 800 Mbps of bandwidth, up to 6 MLTs per switch or per stack.Up to 32 port-based VLANs can be established for each switch, to extend the broadcast domain and segment network traffic for higher network efficiency.Support for up to 8,000 MAC addresses provides scalability for growing networks with many attached devices and workgroups connected to each switch.Standalone or stacked switches can be managed from the Web as a single entity with one IP address, using free software from Nortel Networks-or managed with Nortel Networks Optivity Network Management software.

Certifications & Standards

IEEE 802.3IEEE 802.3uIEEE 802.3xIEEE 802.3zIEEE 802.1DIEEE 802.1Q Electromagnetic Emissions US: FCC Part 15, Subpart B, Class ACanada: ICES-003, Issue-2, Class AJapan: VCCI V-3/99.04, Class AAustralia/New Zealand: AS/NZS 3548: 1997, Class ATaiwan: BSMIEurope: CISPR 22: 1997, Class AEN 55022: 1998, Class AEN 61000-3-2: 1998, Class AEN 61000-3-3: 1995EN 55024CESafety Standards Certification:US: UL 1950 (Third Edition)UL-94V-1 Flammability requirement for PCBsCanada: CSA-C22.2 No. 950-95Europe: TUV, EN 60950, IEC 60950Mexico: NOM - 019

Weight (Approximate)

6.20 lb

Form Factor

Desktop

Height

1.8"

Width

17.1"

Depth

8"

Input Voltage

220 V AC

Power Source

Power Supply

Management

BootP and TFTP support for centralized administration tasksuser and administrator authenticationconcurrent RMON on every port (alarms, events, history, statistics)port mirroring for in-depth traffic analysisbackup configuration files on a TFTP server

Manageable

Yes
