FS108P
by Netgear
4 x 10/100Base-TX, 4 x 10/100Base-TX
- Unspsc:
- 43222612
- Upc:
- 814227018997
- Nsn:
- 5930015688478
- Description:
- The ProSafe FS108P provides power and data from a single point, using Power over Ethernet (PoE) over a single Cat-5 cable. The eight Fast Ethernet ports can be used for any 10/100 Mbps link and four of these ports can supply industry-standard IEEE 802.3af power. Advanced auto-sensing algorithm gives power only to 802.3af end devices, so no need to worry about damaging proprietary PoE or non-PoE equipment. In addition, it discontinues the power when PoE devices are disconnected. Easy and reliable, the ProSafe FS108P automatically determines PoE requirements, speed, duplex, and cable type using AutoUplink. The affordable ProSafe FS108P delivers PoE to any small business network that wants to simplify the installation of wireless access points and IP-based surveillance cameras.These devices are optimally installed on a ceiling or high on a wall, away from most electrical outlets. PoE eliminates the requirement for a dedicated electrical outlet to power these devices. This allows for flexibility in situating devices where AC power is difficult to access and lowers installation costs. Compact and flexible, the ProSafe FS108P is ideal for small business network that want to inexpensively use PoE to deploy wireless access points and IP-based network surveillance cameras.
Interfaces/Ports
- Total Number of Network Ports
- 4
General Information
- Product Type
- Ethernet Switch
- Manufacturer Part Number
- FS108P
- Manufacturer Website Address
- http://www.netgear.com
- Manufacturer
- Netgear, Inc
- Product Model
- FS108P
- Product Name
- ProSafe 8 Port 10/100 Switch with Power over Ethernet
- Product Line
- ProSafe
- Brand Name
- Netgear
Media & Performance
- Network Technology
- 10/100Base-TX
- Twisted Pair Cable Standard
- Category 5
- Ethernet Technology
- Fast Ethernet
Miscellaneous
- Additional Information
- Network latency: Less than 20 micro-seconds for 64-byte frames in store-and-forward mode for 100 Mbps to 100 Mbps transmissionAcoustic Noise: 0 dB
Physical Characteristics
- Weight (Approximate)
- 1.70 lb
- Height
- 1.1"
- Width
- 9.3"
- Depth
- 4.1"
Power Description
- Power Source
- AC Adapter
Reliability
- MTBF
- 184082 Hour
