7159-CFV
by Lenovo
Manageable - 54 x Expansion Slots - 1000Base-LX, 1000Base-SX, 1000Base-T, 10GBase-SR, 10GBase-LR, 10GBase-ER, 40GBase-X - Uplink Port - 48, 6 x Expansion Slot, Expansion Slot - Optical Fiber - 10 Gigabit Ethernet, 40 Gigabit Ethernet - 48 x SFP+ Slots - 3 Layer Supported - Power Supply - Redundant Power Supply - 1U High - Rack-mountable - 3 Year
- Description:
- The Lenovo RackSwitch™ G8272 that uses 10Gb SFP+ and 40Gb QSFP+ Ethernet technology is specifically designed for the data center. It is ideal for today's big data, cloud, and optimized workload solutions. It is an enterprise class Layer 2 and Layer 3 full featured switch that delivers line-rate, high-bandwidth switching, filtering, and traffic queuing without delaying data. Large data center-grade buffers help keep traffic moving, while the hot-swap redundant power supplies and fans (along with numerous high-availability features) help provide high availability for business sensitive traffic.
Interfaces/Ports
- Modular
- No
- Uplink Port
- Yes
- Stack Port
- No
- Port/Expansion Slot Details
- 6 x 40 Gigabit Ethernet Expansion Slot
General Information
- Product Type
- Layer 3 Switch
- Manufacturer Part Number
- 7159CFV
- Manufacturer Website Address
- http://www.lenovo.com/us/en/
- Packaged Quantity
- 1
- Manufacturer
- Lenovo Group Limited
- Product Model
- G8272
- Product Name
- RackSwitch G8272 Layer 3 Switch
- Product Line
- RackSwitch
- Brand Name
- Lenovo
I/O Expansions
- Expansion Slot Type
- SFP+
- Number of Total Expansion Slots
- 54
- Number of SFP+ Slots
- 48
Media & Performance
- Network Technology
- 40GBase-X
- Ethernet Technology
- 40 Gigabit Ethernet
- Media Type Supported
- Optical Fiber
Miscellaneous
- Package Contents
- Lenovo RackSwitch G8272 Layer 3 Switch 2 x Power Supplies 4 x Fans Assemblies Generic Rack Mount Kit (2-post) RJ-45 (plug) to RJ-45 (plug) serial cable (1 m) Mini-USB to RJ-45 (jack) adapter cable (0.2 m) with retention clip DB-9 to RJ-45 (jack) adapter Warranty Flyer Important Notices Flyer Documentation CD-ROM
- Green Compliant
- Yes
- Green Compliance Certificate/Authority
- TÜV
Network & Communication
- Layer Supported
- 3
Physical Characteristics
- Weight (Approximate)
- 13.45 lb
- Form Factor
- Rack-mountable
- Height
- 1.7"
- Width
- 19.2"
- Depth
- 17.3"
- Compatible Rack Unit
- 1U
Power Description
- Power Source
- Power Supply
- Redundant Power Supply
- Yes
Management & Protocols
- Manageable
- Yes
Additional Product Specifications
- Full Product Specifications
- Click to view
