QFX5100-24Q-3AFI
by Juniper
Manageable - 26 x Expansion Slots - 40GBase-X - 3 Layer Supported - Redundant Power Supply - 1U High - Rack-mountable - 1 Year
- Unspsc:
- 43222612
- Upc:
- 832938068766
- Description:
- The highly flexible, high-performance Juniper Networks® QFX5100 line of switches provides the foundation for today's and tomorrow's dynamic data center. As a critical enabler for IT transformation, the data center network supports cloud and softwaredefined networking (SDN) adoption, as well as rapid deployment and delivery of applications. Mission-critical applications, network virtualization, and integrated or scale-out storage are driving the need for more adaptable networks. With its diverse set of deployment options, including fabric, Layer 3, and spine and leaf, the QFX5100 is the universal building block for data center switching architectures, enabling users to easily adapt as requirements change over time.
General Information
- Brand Name
- Juniper
- Manufacturer
- Juniper Networks, Inc
- Manufacturer Part Number
- QFX5100-24Q-3AFI
- Manufacturer Website Address
- http://www.juniper.net
- Product Model
- QFX5100-24Q
- Product Name
- QFX5100-24Q Layer 3 Switch
- Product Series
- QFX5100
- Product Type
- Layer 3 Switch
I/O Expansions
- Expansion Slot Type
- QSFP+
- Number of Total Expansion Slots
- 26
Interfaces/Ports
- Bypass
- No
- LRE Port
- No
- Management Port
- Yes
- Port/Expansion Slot Details
- 24 x 40 Gigabit Ethernet Expansion Slot
- Token Ring Port
- No
- Uplink Port
- No
- USB
- Yes
Management & Protocols
- Manageable
- Yes
- Management
- Command Line Interface (CLI) Web-based Management Telnet SNMP v1/2/3 sFlow MIB VLAN DHCP QoS
Media & Performance
- Ethernet Technology
- 40 Gigabit Ethernet
- Network Technology
- 40GBase-X
Memory
- Standard Memory
- 8 GB
Miscellaneous
- Certifications & Standards
- Safety: CAN/CSA-C22.2 No. 60950-1 (2007) Information Technology Equipment-Safety UL 60950-1 (2nd Ed.) Information Technology Equipment-Safety EN 60950-1 (2005) Information Technology Equipment-Safety IEC 60950-1 (2005) Information Technology Equipment-Safety (All country deviations): CB Scheme report. EN 60825-1 +A1+A2 (1994) Safety of Laser Products-Part 1: Equipment Classifcation GR-63-Core (2006) Network Equipment, Building Systems (NEBS) Physical Protection GR-1089-Core (2006) EMC and Electrical Safety for Network Telecommunications Equipment SR-3580 (1995) NEBS Criteria Levels (Level 3) EMC: FCC 47CFR, Part 15 Class A (2009) USA Radiated Emissions EN 55022 Class A (2006)+ A1 2007 European Radiated Emissions VCCI Class A (2007) Japanese Radiated Emissions BSMI CNS 13438 and NCC C6357 Taiwan Radiated Emissions AS/NZS CISPR22:2009 IEEE Standards: 802.1D 802.1w 802.1 802.1Q 802.1p 802.1ad 802.3ad 802.1AB 802.3x 802.1Qbb 802.1Qaz 802.1Qau 802.1Qbg
- Green Compliance Certificate/Authority
- WEEE
- Green Compliant
- Yes
Network & Communication
- Layer Supported
- 3
Physical Characteristics
- Compatible Rack Unit
- 1U
- Depth
- 17.4"
- Form Factor
- Rack-mountable
- Height
- 1.7"
- Weight (Approximate)
- 21.60 lb
- Width
- 20.5"
Power Description
- Input Voltage
- 230 V AC
- PoE (RJ-45) Port
- No
- Power Source
- Power Supply
- Redundant Power Supply
- Yes
Reliability
- MTBF
- 200000 Hour
