EX4300-48T-DC
by Juniper
48 Ports - Manageable - 4 x Expansion Slots - 10/100/1000Base-T - 3 Layer Supported - Redundant Power Supply - 1U High - Rack-mountable, DesktopLifetime Limited Warranty
- Unspsc:
- 43222612
- Upc:
- 832938063587
- Description:
- The Juniper Networks® EX4300 line of Ethernet switches with Virtual Chassis technology combines the carrier-class reliability of modular systems with the economics and flexibility of stackable platforms, delivering a high-performance, scalable solution for data center, campus, and branch office environments. Offering a full suite of Layer 2 and Layer 3 switching capabilities, the EX4300 satisfies a variety of high-performance applications, including branch, campus, and data center access deployments as well as Gigabit Ethernet (GbE) access deployments. A single 24- port or 48-port switch can be deployed initially. As requirements grow, Juniper Networks Virtual Chassis technology allows up to 10 EX4300 switches to be interconnected and managed as a single device, delivering a scalable, pay-as-you-grow solution for expanding network environments. The EX4300 switches can be interconnected over multiple 40GbE quad small form-factor pluggable plus (QSFP+) transceiver ports to form a 320 gigabit per second (Gbps) backplane. Flexible 1GbE and 10GbE uplink options are also available, enabling high-speed connectivity to aggregation- or core-layer switches which connect multiple floors or buildings.prove productivity.
General Information
- Brand Name
- Juniper
- Manufacturer
- Juniper Networks, Inc
- Manufacturer Part Number
- EX4300-48T-DC
- Manufacturer Website Address
- http://www.juniper.net
- Product Model
- EX4300-48T
- Product Name
- EX4300-48T Ethernet Switch
- Product Series
- EX4300
- Product Type
- Ethernet Switch
I/O Expansions
- Expansion Slot Type
- QSFP+
- Number of Total Expansion Slots
- 4
Interfaces/Ports
- Bypass
- No
- LRE Port
- No
- Management Port
- Yes
- Modular
- No
- Number of Network (RJ-45) Ports
- 48
- Port/Expansion Slot Details
- 48 x Gigabit Ethernet Network
- Stack Port
- No
- Token Ring Port
- No
- Total Number of Network Ports
- 48
- USB
- Yes
Management & Protocols
- Manageable
- Yes
- Management
- Junos OS CLI Web-based Management VLAN QoS DHCP SNMP v1, v2c, v3 RMON 1, 2, 3, 9 MIB Telnet
Media & Performance
- Ethernet Technology
- Gigabit Ethernet
- Media Type Supported
- Twisted Pair
- Network Technology
- 10/100/1000Base-T
Memory
- Flash Memory
- 2 GB
- Memory Technology
- DRAM
- Standard Memory
- 2 GB
Miscellaneous
- Certifications & Standards
- IEEE Standards: 802.1p 802.1Q 802.1X 802.1ak 802.3 802.3u 802.3ab 802.3z 802.3ae 802.3ba 802.3af 802.3at 802.3x 802.3ah Safety: UL-UL60950-1 C-UL to CAN/CSA 22.2 No. 60950-1 TUV/GS to EN 60950-1 EN 60950-1 IEC 60950-1 EMC: FCC 47CFR Part 15 Class A EN 55022 Class A ICES-003 Class A VCCI Class A AS/NZS CISPR 22 Class A CISPR 22 Class A EN 55024 EN 300386 CE
- Green Compliance Certificate/Authority
- RoHS-6
- Green Compliant
- Yes
- Package Contents
- EX4300-48T Ethernet Switch DC Power Supply 2 x Fan Modules
Network & Communication
- Layer Supported
- 3
Physical Characteristics
- Compatible Rack Unit
- 1U
- Depth
- 16.4"
- Form Factor
- Rack-mountable
- Height
- 1.7"
- Weight (Approximate)
- 13.01 lb
- Width
- 17.4"
Power Description
- PoE (RJ-45) Port
- No
- Power Source
- Power Supply
- Redundant Power Supply
- Yes
