90P1319
by Ibm
SCSI - 15000 - 8 MB Buffer - Hot Swappable
- Unspsc:
- 43201803
- Upc:
- 102645787251
- Nsn:
- 7025015310812
- Description:
- Increase your throughput in select IBM eServer xSeries servers with the next generation of high-speed Ultra320 SCSI hard disk drives (HDDs), now with the new Ultra-Slim tray form factor. Ultra320 SCSI drives provide top-of-the-line performance for business-critical, disk-intensive applications such as e-business, transaction processing, data mining and data warehousing. Ultra320 SCSI technology combines interface data transfer rates of up to 320MBps, reduced overhead and enhanced flow control to help deliver dramatic performance gains. This HDD option provides a high-performance, wide bandwidth data path to provide high levels of performance. And at 15,000rpm spindle speeds, these are IBM's highest-performing HDDs. Improved diagnostics and data protection, as well as hot-swap capabilities with direct docking, help reduce downtime. For even greater reliability, you can create high-perfomance RAID arrays. Simply connect your drives to either an onboard Ultra320 SCSI controller with integrated mirroring capabilities or an IBM ServeRAID-6M Controller, available on select xSeries servers.
Interfaces/Ports
- Drive Interface
- SCSI
- Drive Interface Standard
- Ultra320 SCSI
Drive Performance
- Buffer
- 8 MB
- Maximum External Data Transfer Rate
- 320 MB/s (2.5 Gbit/s)
- Maximum Internal Data Transfer Rate
- 78 MB/s (624 Mbit/s)
- Average Latency
- 3 ms
- Spindle Speed (rpm)
- 15000
General Information
- Product Type
- Hard Drive
- Manufacturer Part Number
- 90P1319
- Manufacturer Website Address
- http://www.ibm.com
- Manufacturer
- IBM Corporation
- Product Name
- U320 SCSI Optional Hard Drive
- Brand Name
- IBM
Miscellaneous
- Compatibility
- PCIBM eServer xSeries
- Device Supported
- Server
Physical Characteristics
- Hot Swappable
- Yes
- Drive Type
- Internal
- Drive Width
- 3.5"
Technical Information
- Storage Capacity
- 73.40 GB
