AW593B
by Hp
Serial Attached SCSI (SAS) Controller - 12 x Total Bays - 6Gb/s SAS, Serial ATA/300 - 6Gb/s SAS - 0, 1, 3, 5, 6, 10, 50, JBOD RAID Levels - 2U Rack-mountable
- Unspsc:
- 43201802
- Upc:
- 887111210500
- Description:
- Large companies that have multiple smaller departments and/or remote locations, and smaller companies whose storage needs demand shared resourcesHow can the flexibility of the HP P2000 G3 MSA Array Systems help remedy large storage needs and small budgets? By offering high-performance 8 Gb FC, Combo FC/iSCSI, 6 Gb SAS, 1 Gb or 10 GbE iSCSI connected arrays designed for efficient storage consolidation at affordable prices. The FC/iSCSI Combo controller gives the flexibility to share the array resources over two protocols, supporting the needs of dissimilar departments and budgets. All P2000 G3 MSA Arrays ship standard with 64 Snapshots and Volume Copy enabled for increased data protection. The FC, Combo FC/iSCSI, and iSCSI controllers allow replication with optional Remote Snap software. The arrays allow departments and small to medium businesses to grow capacity as needed up to 149 drives. Mixing of LFF and SFF enterprise-class SAS and archival-class SATA drives is supported. Configure with a single controller for low initial cost, or dual controllers for high availability for the most demanding entry-level situations.
Controllers
- Controller Type
- Serial Attached SCSI (SAS)
- RAID Levels
- 0, 1, 3, 5, 6, 10, 50, JBOD
General Information
- Brand Name
- HP
- Manufacturer
- Hewlett Packard Enterprise
- Manufacturer Part Number
- AW593B
- Manufacturer Website Address
- http://www.hp.com
- Product Line
- StorageWorks
- Product Model
- P2000 G3
- Product Name
- P2000 G3 SAS MSA Dual Controller LFF Array System
- Product Series
- P2000
- Product Type
- DAS Array
I/O Expansions
- Number of 2.5" Bays
- No
- Number of 2.5"/3.5" Bays
- No
- Number of 3.5" Bays
- 12
- Number of 5.25" Bays
- No
- Number of Total Expansion Bays
- 12
Interfaces/Ports
- Drive Interface
- Serial ATA/300
- Host Interface
- 6Gb/s SAS
Management & Protocols
- Protocols
- Telnet
Miscellaneous
- Compatibility
- HP c-Class Blade ServersIntegrity servers, IA64 (FC and FC/iSCSI support only)HP Proliant Servers:DLML
- Green Compliance Certificate/Authority
- RoHS 2
- Green Compliant
- Yes
- Platform Supported
- PC
Physical Characteristics
- Depth
- 28.7"
- Form Factor
- Rack-mountable
- Height
- 10.6"
- Rack Height
- 2U
- Weight (Approximate)
- 42.33 lb
- Width
- 25.5"
Power Description
- Number of Power Supplies Installed
- 2
- Redundant Power Supply
- Yes
Storage
- Number of Hard Drives Installed
- No
- Number of Hard Drives Supported
- 12
- Total Hard Drive Capacity Supported
- 36 TB
