Hp 5 Ports Manageable 4 X Expansion Slots 10 100 1000base T 10gbase Cx4 Uplink Port 2 X Sfp Slots 3 Layer Supported Desktop 498358b21
Recycle
Conditions Available
Lock
Warranties Available

498358-B21
by Hp
5 Ports - Manageable - 4 x Expansion Slots - 10/100/1000Base-T, 10GBase-CX4 - Uplink Port - 2 x SFP Slots - 3 Layer Supported - Desktop


Unspsc:
43222612
Description:
Designed specifically for the c-Class BladeSystem enclosure, the HP 6120G/XG Blade Switch provides sixteen 1Gbdownlinks and four 1Gb copper uplinks, two 1Gb SFP uplinks along with three 10Gb uplinks and a single 10Gb cross-connect. A robust set of industry standard Enhanced Layer 2 switching functions, QOS metering, security and High Availability features round out this extremely capable switch. The 6120G/XG is perfectly suited for datacenters in transition where a mix of 1Gb and 10Gb network connections are required. The 6120G/XG part of HP's data center solutions for blade enclosures that provides consistency and interoperability across existing network investments to help reduce the complexity of network management through resilient core-to-edge connectivity and automated provisioning technologies. With a variety of connection interfaces the 6120G/XG switch offers excellent investment protection, flexibility, and scalability, as well as ease of deployment and reduced operational expense.
Interfaces/Ports
Token Ring Port
No
LRE Port
No
USB
Yes
Number of Network (RJ-45) Ports
4
Modular
No
Uplink Port
Yes
Stack Port
No
Bypass
No
Total Number of Network Ports
5
Port/Expansion Slot Details
1 x 10 Gigabit Ethernet Uplink
General Information
Product Type
Ethernet Switch
Manufacturer Part Number
498358-B21
Packaged Quantity
1
Manufacturer
HP-IMSourcing
Product Model
6120G/XG
Product Name
6120G/XG Ethernet Blade Switch
Product Line
ProCurve
Brand Name
HP-IMSourcing
I/O Expansions
Expansion Slot Type
XFP
Number of Total Expansion Slots
4
Number of SFP Slots
2
Number of XFP Slots
3
Shared SFP Slot
No
Media & Performance
Network Technology
10GBase-CX4
Ethernet Technology
10 Gigabit Ethernet
Media Type Supported
Twisted Pair
Memory
Flash Memory
256 MB
Standard Memory
512 MB
Miscellaneous
Package Contents
6120G/XG Ethernet Blade Switch 1 x Mini USB Management Cable Getting Started Guide
Certifications & Standards
FCC Class A CSA CISPR 22 Class A CISPR 24 cUL EN 60950 EN55022 IEC 61000-3-2 IEC 61000-3-3 IEC 61000-4-11 IEC 61000-4-2 IEC 61000-4-3 IEC 61000-4-4 IEC 61000-4-5 IEC 61000-4-6 IEC 61000-4-8 IEC950 NOM UL 1950 VCCI-I IEEE Standards: 802.3 802.3u 802.1D 802.1Q 802.3ab 802.1p 802.3x 802.3ad 802.1w 802.1x
Green Compliant
Yes
Green Compliance Certificate/Authority
RoHS
Network & Communication
Layer Supported
3
Physical Characteristics
Weight (Approximate)
4.41 lb
Form Factor
Desktop
Height
2.4"
Width
14.5"
Depth
11.4"
Power Description
Input Voltage
12 V DC
Power Source
AC Adapter
PoE (RJ-45) Port
No
Management & Protocols
Management
ProCurve Manager QoS VLAN Web-based Management SNMP v1, v2c, v3 RMON v1, v2 DHCP Telnet Syslog CLI
Manageable
Yes
