Conditions Available
Warranties Available
J4139A
by Hp
4 x Expansion Slot
- Unspsc:
- 43222612
- Upc:
- 88698744895
- Description:
- The HP ProCurve Routing Switch 9304m delivers a new level of high-performance capabilities and investment protection for medium and large enterprise networks. By providing high-performance throughput from the wiring closet into the data center and out to the edge of the WAN, the Routing Switch 9304m non-blocking architecture enables network managers to build scalable and highly available network designs.
Interfaces/Ports
- Management Port
- Yes
General Information
- Product Type
- Switch Chassis
- Manufacturer Part Number
- J4139A
- Manufacturer Website Address
- http://www.hp.com
- Manufacturer
- Hewlett-Packard
- Product Model
- 9304m
- Product Name
- ProCurve Routing 9304m Switch Chassis
- Product Line
- ProCurve
- Product Series
- 9300m
- Brand Name
- HP
I/O Expansions
- Number of Total Expansion Slots
- 4
Miscellaneous
- Additional Information
- Latency: <7 µs (FIFO)Operating relative humidity: 5% to 90% @ 104°F (40°C), non-condensingNon-operating/storage relative humidity: 95% @ 149°F (65°C), non-condensingSupports a maximum of 6 10-GbE, 56 Gigabit, or 144 10/100 ports, or a combination
- Package Contents
- HP ProCurve Routing Switch 9304m19 in. rack hardwareHP ProCurve Manager
- Certifications & Standards
- IEEE 802.3ad: Link Aggregation Control ProtocolIEEE 802.1w: Rapid Convergence Spanning TreeIEEE 802.1X: Network LoginIEEE 802.3: EthernetIEEE 802.3U: Fast EthernetIEEE 802.3z: Gigabit EthernetIEEE 802.3x: Flow ControlRFC 1058: RIPRFC 1583: OSPFv2IEEE 802.1D: Spanning TreeIEEE 802.1Q: VLANsIEEE 802.1Q: VLAN taggingRFC 1493: Bridge MIBIEEE 802.3: Ethernet MIBRepeater MIBEthernet Interface MIBRFC 2819: RMON groups: 1 (statistics), 2 (history), 3 (alarm), and 9 (events)IEEE 802.1p: PriorityRFC 1075: DVMRPRFC 1723: RIPv2Shock and vibration:EN 60068 (IEC 68)Safety:EN 60950/IEC 950UL 1950CSA 950Emissions:FCC Class AEN 55022/CISPR 22 Class AVCCI Class AImmunity:ESD: IEC 61000-4-2; 4 kV CD, 8 kV ADRadiated: IEC 61000-4-3; 3V/mEFT/Burst: IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal line)Conducted: IEC 61000-4-6; 3V
Network & Communication
- Layer Supported
- 4
Physical Characteristics
- Weight (Approximate)
- 60 lb
- Color
- Black
- Height
- 9"
- Width
- 17.5"
- Depth
- 15"
Power Description
- Input Voltage
- 220 V AC
- Power Source
- Power Supply
- Redundant Power Supply
- Yes
Management & Protocols
- Management
- HP ProCurve ManagerHP ProCurve Manager PlusSNMPv1SNMPv2cSNMPv3RMON 1RMON 2RMON 3RMON 9Web interfaceCommand line interface
- Manageable
- Yes
CISCO srw248g4
