Eaton Corporation 3 Minute Full Load 11 Minute Half Load 5 Kva 4 50 Kw Snmp Manageable 2 2 X Nema L6 20r Nema L6 30r Hardwired 9px5k
Recycle
Conditions Available
Lock
Warranties Available

9PX5K
by Eaton Corporation
3 Minute Full Load - 11 Minute Half Load - 5 kVA / 4.50 kW - SNMP Manageable - 2, 2 x NEMA L6-20R, NEMA L6-30R, Hardwired


Unspsc:
39121011
Upc:
11411242378
Description:
The Eaton 9PX UPS provides energy-efficient power protection for small & medium Datacentres, IT rooms and Infrastructure. Delivering double conversion protection with 40% less energy usage and 28% more power 9PX is the perfect UPS for IT and Facility managers that are concerned by energy cost and are looking for next generation power protection solutions.
Battery Information
Battery Chemistry
Lead Acid
Backup/Run Time (Half Load)
11 Minute
Backup/Run Time (Full Load)
3 Minute
Battery Characteristics
Maintenance-free/Sealed
Interfaces/Ports
USB
Yes
Network (RJ-45)
Yes
Serial Port
Yes
General Information
Product Type
Dual Conversion Online UPS
Manufacturer Part Number
9PX5K
Manufacturer Website Address
http://www.eaton.com/EatonCom/Markets/NorthAmerica
Manufacturer
Eaton Corporation
Product Name
9PX5K 5kVA UPS
Product Series
9PX
Brand Name
Eaton
Management
Bypass Switch
Optional
Emergency Power OFF
Yes
Network Management
SNMP Manageable
Overload Protection
Yes
Miscellaneous
Package Contents
9PX5K 5kVA UPSNetwork-MS Web/SNMP Card4-Post Rail KitUser ManualQuick Start GuideTower PedestalsIntelligent Power Software Suite CDRS-232 Serial CableUSB CableCable Gland for Hardwire ConectionPhillips Head Screw Driver
Software Included
Eaton Intelligent Power Software
Green Compliant
Yes
Green Compliance Certificate/Authority
RoHS
Physical Characteristics
Weight (Approximate)
105.82 lb
Form Factor
Tower/Rack Mountable
Rack Height
3U
Height
5.1"
Width
17"
Depth
28"
Power Description
Input Voltage
220 V AC
Output Voltage
240 V AC
Frequency
50 Hz to 70 Hz
Load Capacity (VA)
5 kVA
Load Capacity (Watt)
4.50 kW
Technical Information
Switching Time
0 ns
Receptacles
Hardwired
Plug/Connector Type
NEMA L6-30P
