Conditions Available
Warranties Available
C6880-X-LE
by Cisco
Manageable - 20 x Expansion Slots - 10GBase-X - 16 x SFP+ Slots - 3 Layer Supported - Redundant Power Supply - Rack-mountable, Desktop - 1 Year
- Unspsc:
- 43222612
- Upc:
- 882658637933
- Description:
- Network traffic has grown exponentially over the last several years, and this trend is expected to continue into the foreseeable future. By 2016, there will be 19 billion networked devices, up from 10 billion in 2011. Business IP traffic is expected to reach 13.1 exabytes per month in 2016. Networks must be capable of scaling well beyond the needs of today to deal with the traffic of tomorrow while at the same time providing investment protection.
Interfaces/Ports
- Token Ring Port
- No
- LRE Port
- No
- USB
- Yes
- Management Port
- Yes
- Bypass
- No
- Port/Expansion Slot Details
- 16 x 10 Gigabit Ethernet Expansion Slot
General Information
- Product Type
- Switch Chassis
- Manufacturer Part Number
- C6880-X-LE
- Manufacturer Website Address
- http://www.cisco.com
- Manufacturer
- Cisco Systems, Inc
- Product Name
- Catalyst 6880-X-Chassis (Standard Tables)
- Product Line
- Catalyst
- Product Series
- 6880-X
- Brand Name
- Cisco
I/O Expansions
- Expansion Slot Type
- Port Card
- Number of Total Expansion Slots
- 20
- Number of SFP+ Slots
- 16
Media & Performance
- Network Technology
- 10GBase-X
- Ethernet Technology
- 10 Gigabit Ethernet
Memory
- Standard Memory
- 2 GB
Miscellaneous
- Certifications & Standards
- Safety: UL 60950 Second Edition CAN/CSA-C22.2 No. 60950 Second Edition EN 60950 Second Edition IEC 60950 Second Edition AS/NZS 60950 EMC: FCC Part 15 (CFR 47) Class A VCCI Class A EN55022 Class A CISPR 22 Class A CE marking AS/NZS 3548 Class A ETS300 386 EN55024 EN61000-6-1 EN50082-1 NEBS/ETSI: GR-1089-Core NEBS Level 3 ETS 300 019 Storage Class 1.1 ETS 300 019 Transportation Class 2.3 ETS 300 019 Stationary Use Class 3.1
Network & Communication
- Layer Supported
- 3
Physical Characteristics
- Form Factor
- Desktop
- Height
- 8.5"
- Width
- 17.4"
- Depth
- 23"
Power Description
- Input Voltage
- 220 V AC
- Power Source
- Power Supply
- Redundant Power Supply
- Yes
- PoE (RJ-45) Port
- No
Management & Protocols
- Management
- MIB RMON VLAN QoS uFlow
- Manageable
- Yes
