WS-C4510R
by Cisco
Manageable - 10 x Expansion Slots - 4 Layer Supported - Power Supply - Redundant Power Supply - 90 Day
- Unspsc:
- 43222612
- Upc:
- 746320803678
- Nsn:
- 5975015320405
- Description:
- The Cisco Catalyst 4510R offers nonblocking Layers 2 through 4 switching with integrated resiliency, further enhancing control of converged networks. Converged voice, video, and data networks with high availability enable business resiliency for enterprise and metropolitan (metro) Ethernet customers deploying Internet-based business applications.An important component of Cisco AVVID (Architecture for Voice, Video and Integrated Data), the Cisco Catalyst 4510R extends control to the network edge with intelligent network services, including sophisticated quality of service (QoS), predictable performance, advanced security, comprehensive management, and integrated resiliency. Offering compatibility with Cisco Catalyst 4000 Series line cards and Supervisor Engines, the Cisco Catalyst 4510R provides an extended window of deployment for the Cisco Catalyst 4000 Series in converged networks. This reduces the cost of ownership by minimizing recurring operational expenses, improving return on investment (ROI).
General Information
- Brand Name
- Cisco
- Manufacturer
- Cisco Systems, Inc
- Manufacturer Part Number
- WS-C4510R
- Manufacturer Website Address
- http://www.cisco.com
- Product Line
- Catalyst
- Product Model
- 4510R
- Product Name
- Catalyst 4510R Switch Chassis
- Product Series
- 4500
- Product Type
- Switch Chassis
I/O Expansions
- Number of Total Expansion Slots
- 10
Management & Protocols
- Manageable
- Yes
- Management
- Support provided by Cisco Works Resource Manager Essentials (a component of LAN Management Solution [LMS]):Builds and maintains an up-to-date hardware and software inventoryMaintains an active archive and simplifies deployment of configuration changes to multiple devicesSimplifies and accelerates software image analysis and automates deploymentRecords and displays comprehensive reports of software, hardware, and configuration changesHighlights critical devices and their ability to respondIsolates network error conditions and suggests probable causesSupport provided by Cisco Works Resource Manager Essentials (a component of LMS):Network topology discovery and display servicesVLAN provisioning and logical display representationTraffic monitoring and performance assessmentEnd station tracking with search utilitiesCiscoView graphical device managementNetwork topology integrity checkingSimple Network Management Protocol (SNMP) Version 1SNMP Version 2cCisco Workgroup Management Information Base (MIB)Ethernet MIBEthernet Repeater MIBSNMP MIB IIRemote Monitoring (RMON)RMON IIInterface tableBridge MIBSwitched Port Analyzer (SPAN)Enhanced Switched Port Analyzer (ESPAN)Port snooping and connection steeringTelnet, Trivial File Transfer Protocol (TFTP), and Bootstrap Protocol (BOOTP) for management access
Miscellaneous
- Additional Information
- Number of Power Supply Bays: 2
- Certifications & Standards
- Ethernet:IEEE 802.3: 10BASE-TFast Ethernet:IEEE 802.3u: 100BASE-TX, 100BASE-FXGigabit Ethernet:IEEE 802.3zIEEE 802.3xIEEE 802.3ab1000BASE-X (GBIC):1000BASE-SX1000BASE-LX/LH1000BASE-ZXVirtual LAN (VLAN) trunking/tagging:IEEE 802.1QIEEE 802.3adSpanning-Tree Protocol:IEEE 802.1DIEEE 802.1wIEEE 802.1sSecurity:IEEE 802.1xPower over Ethernet (PoE):IEEE 802.3afRFCs:RFCs 1155-1157RFC 1643RFC 1516RFC 1213RFC 1757RFC 2021RFC 1573RFC 1493Regulatory compliance:CE markingSafety:UL 60950CAN/CSA-C22.2 No. 60950EN 60950IEC 60950TS 001AS/NZS 3260EMC:FCC Part 15 (CFR 47) Class AICES-003 Class AEN55022 Class ACISPR22 Class AAS/NZS 3548 Class AVCCI Class AEN 55022EN 55024EN 61000-6-1EN 50082-1EN 61000-3-2EN 61000-3-3ETS 300 386Industry EMC, safety, and environmental standards:GR-63-Core Network Equipment Building Standards (NEBS) Level 3GR-1089-Core Level 3ETS 300 019 Storage Class 1.1ETS 300 019 Transportation Class 2.3 (pending)ETS 300 019 Stationary Use Class 3.1ETS 300 386Telecom (E1):CTR 12/13CTR 4ACA TS016Telecom (T1):FCC Part 68Canada CS-03JATE Green Book
- Package Contents
- Catalyst 4510R Switch Chassis19-inch rack and cable guide hardware
- System Requirements
- The 1400W AC and 2800W AC power supplies are required to support a fully loaded Catalyst 4510R. The 1000W AC and 1300W AC power supplies can be deployed in the 4510R; however, power management is required
Network & Communication
- Layer Supported
- 4
Physical Characteristics
- Depth
- 12.5"
- Height
- 24.4"
- Weight (Approximate)
- 51.50 lb
- Width
- 17.3"
Power Description
- Power Source
- Power Supply
- Redundant Power Supply
- Yes
