A901-4C-F-D
by Cisco
8 Ports - Management Port - 8 Slots - Gigabit Ethernet - Redundant Power Supply - 1U - Rack-mountable
- Unspsc:
- 43222609
- Upc:
- 882658500466
- Description:
- The Cisco® ASR 901 Series Aggregation Services Routers are environmentally hardened, high-speed, low-power-consumption routers optimized for any-generation cell-site Radio Access Network (RAN) backhaul and Ethernet access. By using Cisco ASR 901 routers, operators can reduce backhaul operating costs, simplify and converge their RAN and Ethernet access networks, and enhance their profit opportunities with mobile and premium Ethernet services.RAN cell sites are places of transformation between mobile radio and mobile transport networks. Cost-effective RAN backhaul requires the ability to simultaneously aggregate the transport of traffic from both traditional and new-generation radios across multiple transport options available at the cell site. The Cisco ASR 901 routers are designed to minimize operating costs and optimize this radio-to-transport transformation through scalable time-division multiplexing (TDM) and IP/Ethernet interfaces for any combination of multivendor, multigeneration radios and transport networks.
General Information
- Brand Name
- Cisco
- Manufacturer
- Cisco Systems, Inc
- Manufacturer Part Number
- A901-4C-F-D
- Manufacturer Website Address
- http://www.cisco.com
- Product Model
- ASR 901-4C-F-D
- Product Name
- ASR 901 Series Aggregation Services Router Chassis
- Product Series
- ASR 901
- Product Type
- Router
I/O Expansions
- Expansion Slot Type
- SFP (mini-GBIC)
- Number of Total Expansion Slots
- 8
Interfaces/Ports
- Management Port
- Yes
- Number of Network (RJ-45) Ports
- 8
- Powerline
- No
- Serial V.35 Interface
- No
- Token Ring Port
- No
- Total Number of Ports
- 8
Management & Protocols
- Security Features
- RADIUSTACACS+Secure Shell v.2 (SSH2)Layer 3 ACLs
Memory
- Flash Memory
- 128 MB
- Memory Technology
- DDR3 SDRAM
- Standard Memory
- 512 MB
Miscellaneous
- Certifications & Standards
- ISO/IEC 9314-3ANSI X3.263-1995IEEE Standards:802.1q802.1ad802.3ad802.1p802.1ag802.3802.3ae802.3ahSafety:UL/CSA 60950-1IEC/EN 60950-1AS/NZS 60950.1EMC Emissions:FCC 47CFR15, Class AEN55022, Class ACISPR 22, Class AAS/NZS CISPR 22, Class AICES 003, Class AVCCI, Class AKN 22, Class AEMC Immunity:EN/IEC61000-4-2EN/IEC61000-4-3EN/IEC61000-4-4EN/IEC61000-4-5EN/IEC61000-4-6NEBS:GR-63-COREGR-1089-COREETSI/EN:EN 300 386EN55022EN55024EN61000-6-1Network Synchronization:GR-1244-COREITU-T G.813ITU-T G.703 clause 5ITU-T G.703 clause 9ITU-T G.8261/Y.1361ITU-T G.781ITU-T G.8264IEEE1588-20
- Green Compliance Certificate/Authority
- RoHS
- Green Compliant
- Yes
Network & Communication
- Ethernet Technology
- Gigabit Ethernet
- Network Technology
- 10/100/1000Base-T
Physical Characteristics
- Compatible Rack Unit
- 1U
- Depth
- 8.3"
- Form Factor
- Rack-mountable
- Height
- 1.7"
- Weight (Approximate)
- 6.80 lb
- Width
- 17.5"
Power Description
- PoE (RJ-45) Port
- No
- Power Source
- Power Supply
- Redundant Power Supply
- Yes
