IE-2000-8TC-G-L
by Cisco
8 Ports - Manageable - 2 x Expansion Slots - 10/100Base-TX, 10/100/1000Base-T - Uplink Port - Shared SFP Slot - 2 x SFP Slots - 2 Layer Supported - Redundant Power Supply - Desktop, Rail-mountable - 1 Year
- Unspsc:
- 43222612
- Upc:
- 89476133641
- Description:
- The Cisco® Industrial Ethernet 2000 (IE 2000) Series is a range of compact, industrially ruggedized access switches. IE 2000 series provide customers with ease of use, secure access, and industry leading convergence using Cisco Resilient Ethernet Protocol (REP). Multiple industries such as automotive, oil and gas, mining, transportation, and energy companies are all increasingly requiring IP based networks in their production areas. The newest IE 2000 additions have been designed to support access layer connectivity and to meet the increasing needs for security, voice, and video traffic across industrial networks.
Interfaces/Ports
- Token Ring Port
- No
- LRE Port
- No
- USB
- No
- Number of Network (RJ-45) Ports
- 10
- Modular
- No
- Management Port
- Yes
- Uplink Port
- Yes
- Stack Port
- No
- Bypass
- No
- Total Number of Network Ports
- 8
General Information
- Product Type
- Ethernet Switch
- Manufacturer Part Number
- IE-2000-8TC-G-L
- Manufacturer Website Address
- http://www.cisco.com
- Manufacturer
- Cisco Systems, Inc
- Product Model
- IE-2000-8TC-G-L
- Product Name
- IE-2000-8TC-G-L Ethernet Switch
- Product Series
- IE-2000
- Brand Name
- Cisco
I/O Expansions
- Expansion Slot Type
- SFP
- Number of Total Expansion Slots
- 2
- Number of SFP Slots
- 2
- Shared SFP Slot
- Yes
Media & Performance
- Network Technology
- 10/100/1000Base-T
- Twisted Pair Cable Standard
- Category 5
- Ethernet Technology
- Gigabit Ethernet
- Media Type Supported
- Twisted Pair
Memory
- Flash Memory
- 64 MB
- Maximum Memory
- 1 GB
- Standard Memory
- 256 MB
- Memory Technology
- DRAM
- Memory Card Supported
- SD
Miscellaneous
- Certifications & Standards
- Safety:UL/CSA 60950-1EN 60950-1CB to IEC 60950-1 (with country deviations)NOM to NOM-019-SCF1 (through partners and distributors)CE MarkingHazard:ANSI/ISA 12.12.01 (Class 1, Div 2 A-D)EN 60079-0, -15 ATEX certification (Class I, Zone 2 A-D)EMC Emission and Community:FCC 47 CFR Part 15 Class AEN 55022A Class AVCCI Class AAS/NZS CISPR 22 Class A, AS/NZS CISPR 24CISPR11 Class A, CISPR22 Class AICES 003 Class AKCC -KoreaCE MarkingC-Tick (Australia)Russia certificationBrazil certificationIEC/EN61000-4-2 (Electro Static Discharge), 15kV Air/8kV ContactIEC/EN 61000-4-3 (Radiated Immunity, 10 and 20V/m)IEC/EN 61000-4-4 (Fast Transients - 4kV power line, 4kV data lineIEC/EN 61000-4-5 (Surge 2 kV/1 kV)IEC/EN 61000-4-6 (Conducted Immunity, 10V/emf)IEC/EN 61000-4-8 (Power Frequency Magnetic Field Immunity)IEC/EN 61000-4-9 (Pulse Magnetic Field Immunity)IEC/EN 61000-4-10 (Oscillatory Magnetic Field Immunity)IEC/EN 61000-4-11 (AC power Voltage Immunity)IEC/EN 61000-4-29 (Voltage Dips Immunity)IEC/EN 61000-6-1 (Immunity for Light Industrial Environments)IEC/EN 61000-6-4 Class AEN 61326Shock and Vibration:IEC 60068-2-27 (Operational Shock: 30G 11ms, half sine)IEC 60068-2-27 (Non-Operational Shock 55-70G, trapezoidal)IEC 60068-2-6, IEC 60068-2-64 (Operational Vibration 2g@10-500Hz)IEC 60068-2-6, IEC 60068-2-64 (Non-operational Vibration)Industry:UL 508CSA C22.2 No. 142EN 61131-2 (Programmable Controllers)Protective CoatingSubstation (IEEE 1613, IEC 61850-3) KEMALloyd's Register Type Approval - ENV2 or ENV3British, German LloydsMarine (LR, BV, GL, DnV, Rina ABS, KR)RA 156-165 Mhz 24 dBuV/M - Class A is 50 dBuV/M - Marine BandRailway EN 50155NEMA TS-2IP30ODVA Industrial EtherNet/IPPROFINETv2Corrosive Testing:ISO-12944-6IEC-60068-2-60Humidity:IEC 60068-52-2 (Salt Fog Mist, Test Kb) Marine environmentsIEC 60068 -2-3IEC 60068-2-30Relative Humidity: 5% to 95% Non-condensing
- Green Compliant
- Yes
- Green Compliance Certificate/Authority
- RoHS
Network & Communication
- Layer Supported
- 2
Physical Characteristics
- Form Factor
- Rail-mountable
Power Description
- Input Voltage
- 60 V DC
- Power Source
- Power Supply
- Redundant Power Supply
- Yes
- PoE (RJ-45) Port
- No
Management & Protocols
- Management
- TelnetWeb Base ManagementSNMPCNAVLANCiscoWorks LAN Management Solution (LMS)DHCP
- Manageable
- Yes
