UCSB-B200-M3
by Cisco
768 GB DDR3 SDRAM DDR3-1866/PC3-15000 Maximum RAM Support - Serial Attached SCSI (SAS) RAID Supported Controller - 2 TB HDD Support - Matrox G200e 256 MB Integrated - 2 x Total Bays - 2 2.5" Bay(s) - Processor Support (Xeon)
- Unspsc:
- 43211520
- Upc:
- 882658485350
- Description:
- The Cisco® Unified Computing System™ (Cisco UCS™) combines Cisco UCS B-Series Blade Servers and CSeries Rack Servers with networking and storage access in a single converged system that simplifies management and delivers greater cost efficiency and agility with increased visibility and control. The Cisco UCS B200 M3 Blade Server delivers performance, versatility, and density without compromise. It addresses the broadest set of workloads, from IT and web infrastructure, through distributed database. The enterprise-class Cisco UCS B200 M3 Blade Server further extends the capabilities of the Cisco UCS portfolio in a half-width blade form factor. The Cisco UCS B200 M3 harnesses the power of the latest Intel® Xeon® processor E5-2600 and E5-2600 v2 product families, with up to 768 GB of RAM (using 32-GB DIMMs), two disk drives, and up to dual 4x 10 Gigabit Ethernet throughput. In addition, Cisco UCS has the architectural advantage of not having to power and cool excess switches in each blade chassis. With a larger power budget per blade server, Cisco can design uncompromised expandability and capabilities in its blade servers, as evidenced by the new Cisco UCS B200 M3, with its leading memory slot and drive capacity.
Interfaces/Ports
- Number of SAS Interfaces
- 2
- Network (RJ-45)
- Yes
Controllers
- RAID Levels
- 0, 1
- Controller Type
- Serial Attached SCSI (SAS)
- RAID Supported
- Yes
Display & Graphics
- Graphics Controller Manufacturer
- Matrox
- Graphics Controller Model
- G200e
- Graphics Memory Capacity
- 256 MB
General Information
- Product Type
- Barebone System
- Manufacturer Part Number
- UCSB-B200-M3
- Manufacturer Website Address
- http://www.cisco.com
- Manufacturer
- Cisco Systems, Inc
- Product Name
- Base UCS B200 M3 Blade Server
- Product Series
- B200 M3
- Brand Name
- Cisco
I/O Expansions
- Number of Internal 2.5" Bays
- 2
- Number of Total Expansion Bays
- 2
Memory
- Maximum Memory
- 768 GB
- Memory Technology
- DDR3 SDRAM
- Memory Standard
- DDR3-1866/PC3-15000
- Memory Card Reader
- Yes
- Number of Total Memory Slots
- 24
Network & Communication
- Ethernet Technology
- 10 Gigabit Ethernet
Physical Characteristics
- Weight (Approximate)
- 9.62 lb
- Form Factor
- Blade
- Height
- 2"
- Width
- 8"
- Depth
- 24.4"
Storage
- Total Hard Drive Capacity Supported
- 2 TB
Processor & Chipset
- Processor Supported
- Xeon
- 64-bit Processing
- Yes
- Chipset Manufacturer
- Intel
- Chipset Model
- C600
- Number of Processors Supported
- 2
Software
- Operating System Supported
- Red Hat Enterprise Linux
