WS-C3560G-48PS-E
by Cisco
48 x 10/100/1000Base-T
- Unspsc:
- 43222612
- Upc:
- 636941483758
- Nsn:
- 7025015735884
- Description:
- The Cisco Catalyst 3560 Series is a line of fixed-configuration, enterprise-class switches that include IEEE 802.3af and Cisco prestandard Power over Ethernet (PoE) functionality in Fast Ethernet and Gigabit Ethernet configurations. The Cisco Catalyst 3560 is an ideal access layer switch for small enterprise LAN access or branch-office environments, combining both 10/100/1000 and PoE configurations for maximum productivity and investment protection while enabling the deployment of new applications such as IP telephony, wireless access, video surveillance, building management systems, and remote video kiosks. Customers can deploy networkwide intelligent services-such as advanced quality of service (QoS), rate limiting, access control lists (ACLs), multicast management, and high-performance IP routing-while maintaining the simplicity of traditional LAN switching.
Interfaces/Ports
- Number of Network (RJ-45) Ports
- 48
- Total Number of Network Ports
- 48
- Port/Expansion Slot Details
- 4 x Gigabit Ethernet Expansion Slot
General Information
- Product Type
- Ethernet Switch
- Manufacturer Part Number
- WS-C3560G-48PS-E
- Manufacturer Website Address
- http://www.cisco.com
- Manufacturer
- Cisco Systems, Inc
- Product Model
- 3560G-48PS-E
- Product Name
- Catalyst 3560 Gigabit Ethernet Switch
- Product Line
- Catalyst
- Product Series
- 3560
- Brand Name
- Cisco
I/O Expansions
- Expansion Slot Type
- SFP
- Number of Total Expansion Slots
- 4
- Number of SFP Slots
- 4
Media & Performance
- Network Technology
- 10/100/1000Base-T
- Twisted Pair Cable Standard
- Category 5
- Ethernet Technology
- Gigabit Ethernet
- Media Type Supported
- Twisted Pair
Memory
- Flash Memory
- 32 MB
- Standard Memory
- 128 MB
- Memory Technology
- DRAM
Miscellaneous
- Additional Information
- Advanced IP routingConfigurable up to 11,000 unicast routesAcoustic Noise: 52-58 dBaDC Input Voltages (RPS Input): 14APower Rating: 0.56 kVAConfigurable up to 1000 IGMP groups and multicast routesTelco: Common Language Equipment Identifier (CLEI) codeConfigurable maximum transmission unit (MTU) of up to 9000 bytes, with a maximum Ethernet frame size of 9018 bytes (Jumbo frames), for bridging on Gigabit Ethernet ports, and up to 1546 bytes for bridging of Multiprotocol Label Switching (MPLS) tagged frames on 10/100 ports.POE:Maximum power supplied per port: 15.4WQoS and Control:Advanced QoSGranular Rate Limiting: The Cisco Committed Information Rate (CIR) function guarantees bandwidth in increments as low as 8 kbps.
- Certifications & Standards
- IEEE:IEEE 802.1sIEEE 802.1wIEEE 802.1xIEEE 802.3adIEEE 802.3afIEEE 802.3xIEEE 802.1D Spanning Tree ProtocolIEEE 802.1p CoS PrioritizationIEEE 802.1Q VLANIEEE 802.3 10BASE-T specificationIEEE 802.3u 100BASE-TX specificationIEEE 802.3ab 1000BASE-T specificationIEEE 802.3z 1000BASE-X specificationSafety Certifications:UL to UL 60950, Third EditionC-UL to CAN/CSA C22.2 No. 60950-00, Third EditionTUV/GS to EN 60950:2000CB to IEC 60950 with all country deviationsNOM to NOM-019-SCFICE MarkingElectromagnetic Emissions Certifications:FCC Part 15 Class AEN 55022: 1998 (CISPR22)EN 55024: 1998 (CISPR24)VCCI Class AAS/NZS 3548 Class ACECNS 13438 Class AMICMIB:BRIDGE-MIBCISCO-CDP-MIBCISCO-CLUSTER-MIBCISCO-CONFIG-MAN-MIBCISCO-ENTITY-FRU-CONTROL-MIBCISCO-ENVMON-MIBCISCO-FLASH-MIBCISCO-FTP-CLIENT-MIBCISCO-HSRP-MIBCISCO-HSRP-EXT-MIBCISCO-IGMP-FILTER-MIBCISCO-IMAGE-MIBCISCO-IP-STAT-MIBCISCO-L2L3-INTERFACE-CONFIG-MIBCISCO-MAC-NOTIFICATION-MIBCISCO-MEMORY-POOL-MIBCISCO-PAGP-MIBCISCO-PING-MIBCISCO-PROCESS-MIBCISCO-RTTMON-MIBCISCO-STP-EXTENSIONS-MIBCISCO-SYSLOG-MIBCISCO-TCP-MIBCISCO-VLAN-IFTABLE-RELATIONSHIP-MIBCISCO-VLAN-MEMBERSHIP-MIBCISCO-VTP-MIBENTITY-MIBETHERLIKE-MIBIF-MIBIGMP-MIBIPMROUTE-MIBOLD-CISCO-CHASSIS-MIBOLD-CISCO-FLASH-MIBOLD-CISCO-INTERFACES-MIBOLD-CISCO-IP-MIBOLD-CISCO-SYS-MIBOLD-CISCO-TCP-MIBOLD-CISCO-TS-MIBOSPF-MIB (RFC 1253)PIM-MIBRFC1213-MIBRFC1253-MIBRMON-MIBRMON2-MIBSNMP-FRAMEWORK-MIBSNMP-MPD-MIBSNMP-NOTIFICATION-MIBSNMP-TARGET-MIBSNMPv2-MIBTCP-MIBUDP-MIB
Network & Communication
- Layer Supported
- 4
Physical Characteristics
- Weight (Approximate)
- 15.50 lb
- Height
- 1.7"
- Width
- 17.5"
- Depth
- 16.1"
Management & Protocols
- Management
- SNMPv1, SNMPv2c, and SNMPv3policy managementCommand-line interface (CLI)Resource Manager EssentialsWeb-based managementCisco Network Assistant SoftwareFour thousand VLAN IDs are supportedManagement console port: RJ-45-to-DB-9 cable for PC connectionsService Assurance Agent (SAA) support facilitates service-level management throughout the LAN.Up to 1024 VLANs per switch or stack and up to 128 spanning-tree instances per switch are supportedEmbedded Remote Monitoring (RMON) software agent supports four RMON groups (history, statistics, alarms, and events).VLAN trunks can be created from any port, using either standards-based 802.1Q tagging or the Cisco Inter-Switch Link (ISL) VLAN architecture.Remote SPAN (RSPAN) allows administrators to remotely monitor ports in a Layer 2 switch network from any other switch in the same network.
- Manageable
- Yes
Reliability
- MTBF
- 147000 Hour
