WS-C3850-48T-L
by Cisco
48 Ports - Manageable - Stack Port - 1 x Expansion Slots - 10/100/1000Base-T - Modular - 48 x Network - Twisted Pair - Gigabit Ethernet - 2 Layer Supported - Power Supply - Redundant Power Supply - 1U High - Rack-mountableLifetime Limited Warranty
- Unspsc:
- 43222612
- Upc:
- 779184190752
- Description:
- The Cisco® Catalyst® 3850 Series is the next generation of enterprise-class stackable access-layer switches that provide full convergence between wired and wireless on a single platform. Cisco's new Unified Access Data Plane (UADP) application-specific integrated circuit (ASIC) powers the switch and enables uniform wired-wireless policy enforcement, application visibility, flexibility and application optimization. This convergence is built on the resilience of the new and improved Cisco StackWise-480. The Cisco Catalyst 3850 Series Switches support full IEEE 802.3at Power over Ethernet Plus (PoE+), modular and field-replaceable network modules, redundant fans and power supplies.
Interfaces/Ports
- Token Ring Port
- No
- LRE Port
- No
- USB
- Yes
- Number of Network (RJ-45) Ports
- 48
- Modular
- Yes
- Management Port
- Yes
- Stack Port
- Yes
- Bypass
- No
- Total Number of Network Ports
- 48
- Port/Expansion Slot Details
- 48 x Gigabit Ethernet Network
General Information
- Product Type
- Ethernet Switch
- Manufacturer Part Number
- WS-C3850-48T-L
- Manufacturer Website Address
- http://www.cisco.com
- Manufacturer
- Cisco Systems, Inc
- Product Model
- 3850-48T-L
- Product Name
- Catalyst 3850-48T-L Ethernet Switch
- Product Line
- Catalyst
- Product Series
- 3850
- Brand Name
- Cisco
I/O Expansions
- Number of Total Expansion Slots
- 1
Media & Performance
- Network Technology
- 10/100/1000Base-T
- Twisted Pair Cable Standard
- Category 5e
- Ethernet Technology
- Gigabit Ethernet
- Media Type Supported
- Twisted Pair
Memory
- Flash Memory
- 2 GB
- Standard Memory
- 4 GB
- Memory Technology
- DRAM
Network & Communication
- Layer Supported
- 2
Physical Characteristics
- Weight (Approximate)
- 17 lb
- Form Factor
- Rack-mountable
- Height
- 1.8"
- Width
- 17.5"
- Depth
- 17.7"
- Compatible Rack Unit
- 1U
Power Description
- Input Voltage
- 220 V AC
- Power Source
- Power Supply
- Redundant Power Supply
- Yes
- PoE (RJ-45) Port
- No
Management & Protocols
- Management
- MIBRMON I and IISNMPv1, v2c, v3QOSVLANDHCP
- Manageable
- Yes
Reliability
- MTBF
- 303660 Hour
