WS-C3750X-48U-L
by Cisco
48 Ports - Manageable - Stack Port - 1 x Expansion Slots - 10/100/1000Base-T - Modular - 2 Layer Supported - Redundant Power Supply - 1U High - Rack-mountableLifetime Limited Warranty
- Unspsc:
- 43222612
- Upc:
- 882658533389
- Description:
- The Cisco® Catalyst® 3750-X and 3560-X Series Switches are an enterprise-class lines of stackable and standalone switches, respectively. These switches provide high availability, scalability, security, energy efficiency, and ease of operation with innovative features such as Cisco StackPower (available only on the Catalyst 3750-X), IEEE 802.3at Power over Ethernet Plus (PoE+) configurations, optional network modules, redundant power supplies, and Media Access Control Security (MACsec) features. The Cisco Catalyst 3750-X Series with StackWise® Plus technology provides scalability, ease of management and investment protection for the evolving business needs. The Cisco Catalyst 3750-X and 3560-X enhance productivity by enabling applications such as IP telephony, wireless, and video for borderless network experience.
Interfaces/Ports
- Token Ring Port
- No
- LRE Port
- No
- USB
- Yes
- Modular
- Yes
- Management Port
- Yes
- Number of Stack Ports
- 2
- Stack Port
- Yes
- Bypass
- No
- Total Number of Network Ports
- 48
- Port/Expansion Slot Details
- 1 x Expansion Slot
- Number of UPOE (RJ-45) Ports
- 48
General Information
- Product Type
- Ethernet Switch
- Manufacturer Part Number
- WS-C3750X-48U-L
- Manufacturer Website Address
- http://www.cisco.com
- Manufacturer
- Cisco Systems, Inc
- Product Model
- WS-C3750X-48U-L
- Product Name
- Catalyst WS-C3750X-48U-L Ethernet Switch
- Product Line
- Catalyst
- Product Series
- 3750-X
- Brand Name
- Cisco
I/O Expansions
- Number of Total Expansion Slots
- 1
Media & Performance
- Network Technology
- 10/100/1000Base-T
- Twisted Pair Cable Standard
- Category 5e
- Ethernet Technology
- Gigabit Ethernet
- Media Type Supported
- Twisted Pair
Memory
- Flash Memory
- 64 MB
- Standard Memory
- 256 MB
- Memory Technology
- DRAM
Miscellaneous
- System Requirements
- PC with Windows Vista, XP, or 2000Browser (Internet Explorer 5.5, 6.0, 7.0, Firefox 1.5, 2.0, 3.0 or later) with JavaScript enabledStraight-through or crossover Category 5 Ethernet cable
Network & Communication
- Layer Supported
- 2
Physical Characteristics
- Weight (Approximate)
- 16.76 lb
- Form Factor
- Rack-mountable
- Height
- 1.8"
- Width
- 17.5"
- Depth
- 19.5"
- Compatible Rack Unit
- 1U
Power Description
- Input Voltage
- 220 V AC
- Power Source
- Power Supply
- Redundant Power Supply
- Yes
- PoE (RJ-45) Port
- No
Management & Protocols
- Management
- Cisco Network AssistantCiscoWorks LAN Management SolutionSNMP v1, v2c, v3RMON 1, 2, 3, 9VLANQoSMIBDHCPSyslog
- Manageable
- Yes
Reliability
- MTBF
- 184120 Hour
