Conditions Available
Warranties Available
WS-C2960X-48TS-L
by Cisco
48 Ports - Manageable - 4 x Expansion Slots - 10/100/1000Base-T - 48, 4 x Network, Expansion Slot - Twisted Pair - Gigabit Ethernet - 4 x SFP Slots - 2 Layer Supported - Power Supply - Redundant Power Supply - 1U High - Rack-mountable, DesktopLifetime Limited Warranty
- Unspsc:
- 43222612
- Upc:
- 801940084590
- Description:
- Catalyst 2960-X series Software FeaturesAll Catalyst 2960-X Series Switches use a single Universal Cisco IOS Software Image for all SKUs. Depending on the switch model, the Cisco IOS image automatically configures either the LAN Lite, LAN Base, or IP Lite feature set.LAN Lite models have reduced functionality and scalability for small deployments with basic requirements. Cisco Catalyst 2960-X Family of Switches are available with the LAN Base and LAN Lite feature sets and Catalyst 2960-XR Family of switches are available IP Lite feature sets.Note that each switch model is tied to a specific feature level; LAN Lite cannot be upgraded to LAN Base and LAN Base cannot be upgraded to IP Lite.
Interfaces/Ports
- Token Ring Port
- No
- LRE Port
- No
- USB
- Yes
- Number of Network (RJ-45) Ports
- 48
- Modular
- No
- Management Port
- Yes
- Bypass
- No
- Total Number of Network Ports
- 48
- Port/Expansion Slot Details
- 4 x Gigabit Ethernet Expansion Slot
General Information
- Product Type
- Ethernet Switch
- Manufacturer Part Number
- WS-C2960X-48TS-L
- Manufacturer Website Address
- http://www.cisco.com
- Manufacturer
- Cisco Systems, Inc
- Product Model
- 2960X-48TS-L
- Product Name
- Catalyst 2960X-48TS-L Ethernet Switch
- Product Line
- Catalyst
- Product Series
- 2960-X
- Brand Name
- Cisco
I/O Expansions
- Expansion Slot Type
- SFP
- Number of Total Expansion Slots
- 4
- Number of SFP Slots
- 4
- Shared SFP Slot
- No
Media & Performance
- Network Technology
- 10/100/1000Base-T
- Twisted Pair Cable Standard
- Category 5
- Ethernet Technology
- Gigabit Ethernet
- Media Type Supported
- Twisted Pair
Memory
- Flash Memory
- 128 MB
- Standard Memory
- 512 MB
- Memory Technology
- DRAM
Miscellaneous
- Certifications & Standards
- IEEE Standards:802.1D802.1p802.1Q802.1s802.1w802.1X802.1ab802.3ad802.3af802.3at802.3ah802.3x802.3802.3u802.3ab802.3z802.3az802.1ae802.3ae802.1axSafety:UL 60950-1 Second EditionCAN/CSA-C22.2 No. 60950-1 Second EditionEN 60950-1 Second EditionIEC 60950-1 Second EditionAS/NZS 60950-1EMC:47CFR Part 15 (CFR 47) Class AAS/NZS CISPR22 Class ACISPR22 Class AEN55022 Class AICES003 Class AVCCI Class AEN61000-3-2EN61000-3-3KN22 Class ACNS13438 Class AEN55024CISPR24EN300386KN24
- Green Compliant
- Yes
- Green Compliance Certificate/Authority
- RoHS
Network & Communication
- Layer Supported
- 2
Physical Characteristics
- Weight (Approximate)
- 9.40 lb
- Form Factor
- Desktop
- Height
- 1.8"
- Width
- 17.5"
- Depth
- 11"
- Compatible Rack Unit
- 1U
Power Description
- Input Voltage
- 220 V AC
- Power Source
- Power Supply
- Redundant Power Supply
- Yes
- PoE (RJ-45) Port
- No
Management & Protocols
- Management
- Web-based ManagementVLANQoSSyslogTelnetRMON I, IISNMP v1, v2c, v3DHCPCLI
- Manageable
- Yes
Reliability
- MTBF
- 442690 Hour
