CISCO3845-V3PN/K9
by Cisco
4 x HWIC, 2 x AIM - 2 x 10/100/1000Base-T LAN, 2 x USB
- Unspsc:
- 43222609
- Upc:
- 746320981611
- Nsn:
- 7025015553496
- Description:
- The integrated services routing architecture of the Cisco 3845 builds on the powerful Cisco 3700 Series routers designed to embed and integrate security and voice processing with advanced services for rapid deployment of new applications, including application layer functions, intelligent network services, and converged communications. The Cisco 3845 supports the bandwidth requirements for multiple Fast Ethernet interfaces per slot, time-division multiplexing (TDM) interconnections, and fully integrated power distribution to modules supporting 802.3af Power over Ethernet (PoE), while still supporting the existing portfolio of modular interfaces.V3PN provides a VPN infrastructure capable of converged data, voice, and video across a highly secure, QoS-enabled IPSec network and allows customers to obtain the same performance for voice and video applications over an IP transport network as they would over an alternate WAN link-securely and effectively. Unlike many VPN devices on the market, Cisco integrated services routers accommodate the diverse network topology and traffic requirements that enable multiservice IPSec VPNs. The end-to-end network architecture of V3PN takes advantage of Cisco security-enabled routers with Cisco IOS Software to secure voice traffic.
Interfaces/Ports
- USB
- Yes
- Number of Network (RJ-45) Ports
- 2
- Management Port
- Yes
- Total Number of Ports
- 2
General Information
- Product Type
- Router
- Manufacturer Part Number
- CISCO3845-V3PN/K9
- Manufacturer Website Address
- http://www.cisco.com
- Manufacturer
- Cisco Systems, Inc
- Product Model
- 3845
- Product Name
- 3845 Integrated Services Router V3PN Bundle
- Product Series
- 3800
- Brand Name
- Cisco
I/O Expansions
- Expansion Slot Type
- SFP (mini-GBIC)
- Number of Total Expansion Slots
- 15
Memory
- Flash Memory
- 64 MB
- Maximum Memory
- 1 GB
- Standard Memory
- 256 MB
- Memory Technology
- SDRAM
Miscellaneous
- Additional Information
- Network-Module slots:These slots can accommodate a standard network-module, enhanced-network-module (NME), enhanced-extended-network-module (NME-X), and high-density extension module (EVM-HD)Maximum number of network modules, NMEs, and NME-Xs supported: 4Maximum number of NMD/NME-XDs supported: 2Maximum number of EVM-HDs supported: 2HWIC slots:These slots also support VICs, VWICs, and WICsPVDM slots:These slots accommodate digital-signal-processor (DSP) modules for packet voice processingRack-Mounting:National Equipment Building Standard (NEBS)/European Telecommunication Standards Institute (ETSI) optionsOperation Altitude:Up to 6500 ft (2000m), derate 1°C per 1000 ftPower Dissipations:AC without IP phone support: 435W (1485 BTU/hr)Noise Level:56 dBa typical, 58 dBa maximum
- Package Contents
- 3845 RouterCisco 3845 IOS ADVANCED IP SERVICESDevice manager for routers (ROUTER-SDM)CallManager Express 3.2 Phantom SKU for CME Orderability (SW-CCME-3.2.0)Cisco CallManager Express Feat License Up To 240 Phones (FL-CCME-240)DES/3DES/AES VPN Encryption/Compression (AIM-VPN/HPII-PLUS)64-Channel Packet Voice/Fax DSP Module (PVDM2-64)Cisco 3845 motherboard (CISCO3845-MB)256MB SDRAM default memory for 3800 (MEM3800-256D-INCL)64MB Cisco 3800 Compact Flash Memory Default (MEM3800-64CF-INCL)Blank WAN Interface Card Panel (WIC-BLANK-PANEL)Cisco 2800 and 3800 Series Blank network module panel (NM-28/38BLNK-PANEL)Cisco 3845 AC power supply (PWR-3845-AC)Power Cord, 110V (CAB-AC)RJ-45-to-DB-9 console cable and RJ-45-to-DB-25 modem cable for management accessOne 2.54-mm (0.100 in.) centerline, single row shuntGround lug and two mounting screwsOne pair of rack-mount brackets with screws for 19-inch (48.26-cm) rack (screws are for bracket-to-chassis attachment)One pair of brackets for 19-inch (48.26-cm) rack (screws are for bracket-to-chassis attachment)Cisco Product Registration CardCisco 3800 Series Integrated Services Routers Regulatory Compliance and Safety Information documentCisco Router and Security Device Manager (SDM) Quick Start Guide documentCisco 3800 Series Integrated Services Routers Quick Start Guide
- Certifications & Standards
- USB 1.1IEEE:IEEE 802.3: 10BASE-TIEEE 802.3u: 100BASE-TXIEEE 802.3ab: 1000BASE-TIEEE 802.1x: AuthenticationSafety:UL 60950CAN/CSA C22.2 No. 60950EN 60950AS/NZS 60950EMC:47 CFR, Part 15ICES-003 Class AEN55022 Class ACISPR22 Class AAS/NZS 3548 Class AVCCI V-3EN 300386EN 61000TELCOM:47 CFR, Part 68TIA/EIA/IS-968CS-03RTTE DirectiveSecurity:FIPS 140-1 Level 2ICSACommon Criteria
Network & Communication
- Network Technology
- 10/100/1000Base-T
- Ethernet Technology
- Gigabit Ethernet
Physical Characteristics
- Weight (Approximate)
- 45 lb
- Form Factor
- Rack-mountable
- Height
- 5.3"
- Width
- 17.3"
- Depth
- 16"
- Compatible Rack Unit
- 3U
Power Description
- Input Voltage
- 220 V AC
- Power Source
- Power Supply
- Redundant Power Supply
- Yes
Management & Protocols
- Security Features
- V3PN: Voice and Video Enabled IPSecAIM-based security accelerationMultiprotocol Label Switching (MPLS) VPN supportSecure ShellEasy VPN Client and ServerIntegrated hardware for offload of encryption services processing supports IPSec DES, 3DES, and AES 128, AES 192, and AES 256 encryption modesAdaptive Threat Defense:Cisco IOS FirewallTransparent FirewallAdvanced Application Inspection and ControlVRF-Aware FirewallIntrusion Prevention (IPS)URL FilteringTrust and Identity:Network Admission Control (NAC)Authentication, Authorization, and Accounting (AAA)802.1x SupportNetwork Foundation Protection:Control Plane PolicingAutoSecureNetwork-Based Application Recognition (NBAR)CPU/memory thresholdingRole-Based CLI Access
