CISCO 803
by Cisco
4 x 10Base-T LAN, 1 x ISDN BRI (S/T) WAN, 2 x WAN
- Nsn:
- 5895014705260
- Description:
- Cisco 800 Series ISDN routers extend the power of Cisco IOS technology to small offices and corporate telecommuters. Cisco IOS technology offers enhanced security, reliability, and safe investment with low cost of ownership to enable customers to benefit from the Internet economy by increasing productivity, simplifying communication, and reducing costs. The Cisco 800 Series enables customers to benefit from value-added services such as managed network services, virtual private networks (VPNs), point-of-sale (POS) applications, and secure Internet access.
Interfaces/Ports
- Number of Network (RJ-45) Ports
- 4
- Management Port
- Yes
- Number of Broadband (RJ-45) Ports
- 1
- Number of RJ-11 Ports
- 2
- Total Number of Ports
- 7
General Information
- Product Type
- Router
- Manufacturer Part Number
- CISCO803
- Manufacturer Website Address
- http://www.cisco.com
- Manufacturer
- Cisco Systems, Inc
- Product Model
- 803
- Product Name
- 803 Router
- Product Series
- 800
- Brand Name
- Cisco
Memory
- Flash Memory
- 8 MB
- Maximum Memory
- 12 MB
- Standard Memory
- 8 MB
- Memory Technology
- DRAM
Miscellaneous
- Additional Information
- ISDN BRI Support: Two B channels plus one D channel: 2 x 64 kbps (precompressed)Interoperable Switched 56: 2 x 56 kbps (precompressed)Single- and multipoint configurationsCompatible with data or voice B-channel ISDN switch typesCTR3 (ETSI, NET3)VN3/4/5 (France) Telephone Support:Telephones: Dual tone multifrequency (DTMF) only (touch-tone only, no pulse)Group III facsimile: V.17, V.27 TER, V.29Modems: V.22, V.22bis, V.32, V.32bis, V.34Dial tone (400 Hz) provided outside of North AmericaRinger equivalency number (REN) = 5.0
- Package Contents
- One Cisco 800 series routerOne yellow Ethernet cableOne orange ISDN S/T cable (Cisco 801 and Cisco 803 only)One red ISDN U cable (Cisco 802 and Cisco 804 only)One RJ-45-to-RJ-11 adapter cable (for use with the red ISDN U cable)One blue console cableOne DB-9-to-RJ-45 adapter (for use with the blue console cable)One DB-25-to-RJ-45 adapter (for use with the blue console cable)One black power supplyOne black power supply cord800 and SOHO Series Product Documentation CDCisco 800 Fast Step CD-ROMCISCO 801-804 4MB TO 8MB DRAM FACTORY UPGRADE (MEM800-4U8D)Cisco 800 Series IOS IPCISCO 801-804 4MB TO 8MB FLASH FACTORY UPGRADE (MEM800-4U8F)
- Certifications & Standards
- IEEE 802.3 Safety Standards:UL 60950, 3rd EditionCSA 22.2 No. 60950EN 60950:1992 with Amendments A1 through A4 and A11IEC 60950 with Amendments A1 through A4 and all country deviationsTS-001:1997AS/NZS 3260 with Amendments A1 through A4CCCNOM-019 EMI Standards:CFR47 part 15 subpart B, 2000 class BEN55022, 1998 class B, CISPR22, 1997 class BEN55024, 1998 Immunity Std, CISPR24, 1997 Immunity StdEN61000-3-2, Harmonics, EN61000-3-3, FlickerEN61000-4-2, Electro Static DischargeEN61000-4-3, Radiated ImmunityEN61000-4-4, Electrical Fast TransientsEN61000-4-5, SurgeEN61000-4-6, Conducted ImmunityEN61000-4-11, Dips and SagsAS/NZS 3548CCC Telecom Standards:FCC part 68/TIA 968CS-03, III, VIIIDirective 1999/5/EC, CTR3JATE, NTTTS013, TS031PTC 231, PTC 270SO 43, C559, TC-003, TC 130, IDA TS ADSL 1 ISSUE 1 2000RSADSL 2AS/ACIF S-043.2YD/T 1055-2000HKTA 2022, 202310 BASE-T PTTPROV-SDL /00-09-25ITU9.991.2
Network & Communication
- Network Technology
- ISDN BRI (S/T)
- Ethernet Technology
- Ethernet
Physical Characteristics
- Weight (Approximate)
- 1.44 lb
- Height
- 2"
- Width
- 9.9"
- Depth
- 8.3"
Power Description
- Input Voltage
- 220 V AC
