ASA5520-AIP10-K9
by Cisco
4 x 1000Base-T , 1 x 10/100Base-TX
- Unspsc:
- 43222502
- Upc:
- 746320987088
- Description:
- The Cisco ASA 5520 Adaptive Security Appliance delivers a wide range of security services with Active/Active high availability and Gigabit Ethernet connectivity for medium-sized enterprise networks, in a modular, high performance appliance. Using its 4 Gigabit Ethernet interfaces and support for up to 25 VLANs, Businesses can easily deploy these security services into multiple zones within their network. The Cisco ASA 5520 Adaptive Security Appliance scales with businesses as their network security requirements grow, delivering solid investment protection. Businesses can extend their IPSec and SSL VPN capacity through multiple means to support a larger number of mobile workers, remote sites, and business partners. VPN capacity can be increased by taking advantage of the integrated VPN clustering and load-balancing capabilities of the Cisco ASA 5520 Adaptive Security Appliance.
Interfaces/Ports
- USB
- Yes
- Management Port
- Yes
- Total Number of Ports
- 5
General Information
- Product Type
- Network Security/Firewall Appliance
- Manufacturer Part Number
- ASA5520-AIP10-K9
- Manufacturer Website Address
- http://www.cisco.com
- Manufacturer
- Cisco Systems, Inc
- Product Model
- ASA 5520
- Product Name
- ASA 5520 VPN/Firewall with SSM-AIP-10
- Product Series
- 5500
- Brand Name
- Cisco
I/O Expansions
- Expansion Slot Type
- SSM
- Number of Total Expansion Slots
- 2
- Number of SSM Slots
- 1
Memory
- Flash Memory
- 64 MB
- Standard Memory
- 512 MB
- Memory Technology
- DRAM
- Memory Card Supported
- CompactFlash
Miscellaneous
- Additional Information
- Concurrent Threat Mitigation Throughput (Firewall + Anti-x Services): Up to 225 MbpsHigh Availability:Active/ActiveActive/Standby
- Package Contents
- ASA 5500 Series Software v7.0ASA 5500 Strong Encryption License (3DES/AES)ASA AIP Security Service Module-10 included with ASA systemsASA 5500 Series AIP Software 5.0 for Security Service ModuleVMS 5 Device Basic LicensePower Cord,110VASA 5500 VPN Base LicenseCisco VPN Client Software (Windows, Solaris, Linux, Mac)
- Certifications & Standards
- USB 2.0Safety:UL 1950CSA C22.2 No. 950EN 60950 IEC 60950AS/NZS3260TS001Electromagnetic Compatibility (EMC):CE markingFCC Part 15 Class AAS/NZS 3548 Class AVCCI Class AEN55022 Class ACISPR22 Class AEN61000-3-2EN61000-3-3IEEE:IEEE 802.3IEEE 802.3uIEEE 802.3abIEEE 802.1Q
Network & Communication
- Network Standard
- 1000Base-T
- Ethernet Technology
- Fast Ethernet
Physical Characteristics
- Weight (Approximate)
- 20 lb
- Form Factor
- Desktop
- Height
- 1.8"
- Width
- 17.5"
- Depth
- 13.2"
- Compatible Rack Unit
- 1U
Power Description
- Input Voltage
- 220 V AC
- Power Source
- Power Supply
Management & Protocols
- Manageable
- Yes
Technical Information
- Firewall Protection
- Intrusion Prevention
- Virtualization
- 130000 x Concurrent Session750 x IPSec VPN Peer750 x Web VPN Peer2 x Security Context10 x Security Context9000 x Concurrent Session
- Encryption Standard
- AES
