ASR-9006-AC-V2
by Cisco
4 Slots - Redundant Power Supply - Rack-mountable
- Unspsc:
- 43201602
- Upc:
- 12304732723
- Description:
- The Cisco ASR 9000 Series is an operationally simple, future-optimized platform using next-generation hardware and software. The following are highlights of this next-generation platform.The Cisco ASR 9000 System brings increased power and simplicity to the edge, and the ASR 9000v sets the industry benchmark as a virtualized compact carrier-class converged access and aggregation platform. Leveraging Cisco's "network virtualization" or nV Technology, the Cisco ASR 9000 System offers exceptional pay as you grow scale, carrier-class reliability, and simplified service provisioning.
Interfaces/Ports
- Management Port
- No
General Information
- Product Type
- Router Chassis
- Manufacturer Part Number
- ASR-9006-AC-V2
- Manufacturer Website Address
- http://www.cisco.com
- Manufacturer
- Cisco Systems, Inc
- Product Model
- ASR 9006
- Product Name
- ASR 9006 Chassis
- Product Series
- ASR 9000
- Brand Name
- Cisco
I/O Expansions
- Expansion Slot Type
- Line Card
- Number of Total Expansion Slots
- 4
Miscellaneous
- Certifications & Standards
- ETSI Standards:EN300 386: Telecommunications Network Equipment (EMC)ETSI 300 019 Storage Class 1.1ETSI 300 019 Transportation Class 2.3ETSI 300 019 Stationary Use Class 3.1EMC Standards Emission:FCC Class 47CFR15 AICES 003 Class AAS/NZS CISRP22 Class ACISPR 22 (EN55022) Class AVCCI Class ABSMI Class AIEC/EN 61000-3-12: Power Line HarmonicsIEC/EN 61000-3-11: Voltage Fluctuations and FlickerEN55022: Information Technology Equipment (Emissions)EN 50121-4: Railway EMCEMC Standards Immunity:IEC/EN-61000-4-2: Electrostatic Discharge Immunity (8kV Contact, 15kV Air)IEC/EN-61000-4-3: Radiated Immunity (10V/m)IEC/EN-61000-4-4: Electrical Fast Transient Immunity (2kV Power, 1kV Signal)IEC/EN-61000-4-5: Surge AC Port (4kV CM, 2kV DM)IEC/EN-61000-4-5: Signal Surge Ports (1kV)IEC/EN-61000-4-5: Surge DC Port (1kV CM, 1kV DM)IEC/EN-61000-4-6: Immunity to Conducted Disturbances (10Vrms)IEC/EN-61000-4-8: Power Frequency Magnetic Field Immunity (30A/m)IEC/EN-61000-4-11: Voltage DIPS, Short Interruptions, and Voltage VariationsEN55024: Information Technology Equipment (Immunity)EN50082-1/EN-61000-6-1: Generic Immunity StandardEN 50121-4: Railway EMCSafety:UL/CSA/IEC/EN 60950-1IEC/EN 60825 Laser SafetyACA TS001AS/NZS 60950FDA Code of Federal Regulations Laser SafetyOSHA acoustic requirements
Network & Communication
- VoIP Supported
- No
Physical Characteristics
- Weight (Approximate)
- 11 lb
- Form Factor
- Rack-mountable
- Height
- 17.5"
- Width
- 17.5"
- Depth
- 31.5"
Power Description
- Power Source
- Power Supply
- Redundant Power Supply
- Yes
- PoE (RJ-45) Port
- No
Management & Protocols
- Security Features
- Authentication, Authorization, and Accounting (AAA)Bridge-Protocol-Data-Unit (BPDU) FilteringControl-Plane ProtectionLayer 2 Control ProtocolAccess Control ListIP Source GuardMAC LimitingSecure ShellTACACS+
