SFE2000P
by Cisco
2 x SFP (mini-GBIC) - 24 x 10/100Base-TX - PoE - LAN, 4 x 10/100/1000Base-T
- Unspsc:
- 43222612
- Upc:
- 808111672785
- Description:
- SFE2000P is optimized for maximizing the system availability with fully redundant Stacking, Redundant Power options, and Dual Images for resilient firmware upgrades. The SFE2000P is able to secure the network through IEEE 802.1Q VLANs, IEEE 802.1X port authentication, Access Control Lists (ACL), DOS Prevention, and MAC-based filtering. The enhanced QoS and traffic management features ensure clear and reliable voice and video communications. Connect up to 24 network devices-PCs, printers, access points, and servers-to share and transfer files and videos across your network
Interfaces/Ports
- Token Ring Port
- No
- LRE Port
- No
- Number of Network (RJ-45) Ports
- 4
- Management Port
- Yes
- Number of PoE (RJ-45) Ports
- 24
- Total Number of Network Ports
- 24
- Port/Expansion Slot Details
- 2 x Gigabit Ethernet Expansion Slot
General Information
- Product Type
- Ethernet Switch
- Manufacturer Part Number
- SFE2000P
- Manufacturer Website Address
- http://www.cisco.com
- Manufacturer
- Cisco Systems, Inc
- Product Model
- SFE2000P
- Product Name
- SFE2000P 24-Port Fast Ethernet Switch with PoE
- Brand Name
- Cisco
I/O Expansions
- Expansion Slot Type
- SFP
- Number of Total Expansion Slots
- 2
- Number of SFP Slots
- 2
- Shared SFP Slot
- Yes
Media & Performance
- Network Technology
- 1000Base-T
- Twisted Pair Cable Standard
- Category 5e
- Ethernet Technology
- Fast Ethernet
- Media Type Supported
- Twisted Pair
Miscellaneous
- Additional Information
- Power over Ethernet powers up to 12 attached devices for increased placement optionsPower redundancy when used with the Cisco RPS1000 Redundant Power SupplyRing and Chain stacking optionsMaster and Backup master for resilient stack controlPower budget allows for max power of 15.4W
- Package Contents
- SFE2000P 24-Port Fast Ethernet Switch with PoEConsole CableAC Power CordRackmount KitQuick-Start Installation Guide
Network & Communication
- Layer Supported
- 2
Physical Characteristics
- Weight (Approximate)
- 10.89 lb
- Form Factor
- Rack-mountable
- Height
- 1.7"
- Width
- 17.3"
- Depth
- 14.7"
Power Description
- Input Voltage
- 220 V AC
- Power Source
- Power Supply
- Redundant Power Supply
- No
- PoE (RJ-45) Port
- Yes
Management & Protocols
- Management
- Web-based ManagementSNMP v1, v2c, v3Telnet ClientIEEE 802.1Q VLANIEEE 802.1p QoSRMONSyslog
- Manageable
- Yes
