WS-C4912G
by Cisco
12 x GBIC
- Unspsc:
- 43222612
- Upc:
- 746320203560
- Nsn:
- 7025014917695
- Description:
- The Catalyst 4912G is a 12-port dedicated Gigabit Ethernet switch featuring high-performance Layer 2 switching and intelligent Cisco IOS network services for high-speed network aggregation. The Catalyst 4912G is the flagship product of the new Catalyst 4900 series, which delivers fixed configuration enterprise platforms providing cost-effective, high-performance solutions for Gigabit networking. The Catalyst 4912G switch provides an advanced enterprise switching solution delivering low-cost, high-density gigabit aggregation with modular Gigabit Interface Converter (GBIC) modular protection. The Catalyst 4912G switch provides intelligent Cisco IOS network services, capable of enhancing LAN scalability, multicasting, security, management and quality of service (QoS). The dedicated gigabit Catalyst 4912G leverages the same feature set with identical software code base and the same enterprise functionality as the Catalyst 5000 family, delivering a consistent end-to-end solution.
Interfaces/Ports
- Port/Expansion Slot Details
- 12 x Gigabit Ethernet Expansion Slot
General Information
- Product Type
- Ethernet Switch
- Manufacturer Part Number
- WS-C4912G
- Manufacturer Website Address
- http://www.cisco.com
- Manufacturer
- Cisco Systems, Inc
- Product Model
- 4912G
- Product Name
- Catalyst 4912G Ethernet Switch
- Product Line
- Catalyst
- Product Series
- 4500
- Brand Name
- Cisco
I/O Expansions
- Expansion Slot Type
- GBIC
- Number of Total Expansion Slots
- 12
- Number of GBIC Slots
- 12
Media & Performance
- Network Technology
- 10Base-T
- Media Type Supported
- Twisted Pair
Memory
- Flash Memory
- 12 MB
Miscellaneous
- Additional Information
- Item Included: Power Cord,110V (CAB-AC)Powerful wire-speed performance with 24 Gbps of dedicated bandwidth for nonblocking Gigabit Ethernet concentrationConsistent and mature Catalyst 5000 family software compatibilityFuture-proof bandwidth protection with broad Gigabit EtherChannel availabilityGBIC flexibility on fiber port interfaces covering a wide range of cabling distancesRedundant, hot-swappable external power supply (option) and other fault-tolerant featuresVirtual LANs (VLANs): 1,024Fabric: Store-and-ForwardQueues: Dual Queuing
- Certifications & Standards
- Safety Certifications: UL 1950EN 60950CSA-C22.2 no 950IEC 950 Electromagnetic Emissions Certifications:FCC 15J Class AVCCI Class BCE MarkingEN 55022 Class BCISPR 22 Class BGigabit Ethernet: IEEE 802.3z, IEEE 802.3x1000BaseX (GBIC) - 1000BaseSX - 1000BaseLX/LH - 1000BaseZXVLAN trunking tagging: IEEE 802.1QSpanning Tree Protocol: IEEE 802.1D1000BaseX (GBIC)
Physical Characteristics
- Weight (Approximate)
- 13 lb
- Height
- 2.8"
- Width
- 17.5"
- Depth
- 15"
Power Description
- Input Voltage
- 220 V AC
- Power Source
- Power Supply
- Redundant Power Supply
- Yes
Management & Protocols
- Management
- CiscoWorks 2000 Network Management Suite, Resource Manager Essentials includes: - Inventory Manager - Change Audit - Device Configuration Manager - Software Image Manager - Availability Manager - Syslog Analyzer - Cisco Management ConnectionCiscoWorks 2000 Network Management Suite, CiscoWorks for Switched Internetworks (CWSI) Campus includes: - Network topology discovery and display services - VLAN provisioning and logical display representation - Traffic monitoring and performance assessment - End-station tracking with search utilities - ATM and LANE service configuration and performance monitoring - CiscoView graphical device management - Network topology integrity checkingCisco Discovery ProtocolCisco Virtual Trunking Protocol (VTP)Simple Network Management Protocol (SNMP) agent v1SNMPv2cCisco workgroup Management Information Base (MIB)Ethernet MIBEthernet repeater MIBSNMP MIB IIRemote monitoring (RMON)Remote monitoring (RMON II)Interface tableBridge MIBSMT 7.3Switched Port Analyzer (SPAN)Enhanced Switched Port Analyzer (ESPAN)Port snooping and connection steeringText-based command-line interface based on the familiar Catalyst 5000 series interfaceStandard Cisco IOS security capabilities: passwords and TACACS+Telnet, Trivial File Transfer Protocol (TFTP), BOOTP for management access
- Manageable
- Yes
