IE-4000-4T4P4G-E
by Cisco
12 Ports - Manageable - 10/100Base-T, 100Base-X, 1000Base-X - Uplink Port - 8, 4 x Network, Uplink - Twisted Pair - Fast Ethernet, Gigabit Ethernet - 3 Layer Supported - Power Supply - Redundant Power Supply - Rail-mountableLifetime Limited Warranty
- Unspsc:
- 43222612
- Upc:
- 882658733406
- Description:
- The Cisco® Industrial Ethernet (IE) 4000 Series is the latest addition to our ruggedized switching platforms and provides superior high-bandwidth switching and proven Cisco IOS® Software-based routing capabilities for industrial environments. The IE 4000 Series delivers highly secure access and industry-leading convergence using the Cisco Resilient Ethernet Protocol (REP) and is built to withstand extreme environments while adhering to overall IT network design, compliance, and performance requirements. The IE 4000 Series is ideal for industrial Ethernet applications where hardened products are required, including factory automation, energy and process control, intelligent transportation systems (ITS), oil and gas field sites, city surveillance programs, and mining. With improved overall performance, greater bandwidth, a richer feature set, and enhanced hardware, the Cisco IE 4000 Series complements the current industrial Ethernet portfolio of related Cisco industrial switches, such as the Cisco IE 2000 and IE 3000. The Cisco IE 4000 can easily be installed in your network. Through a user-friendly web device manager, the Cisco IE 4000 provides easy out-of-the-box configuration and simplified operational manageability to deliver advanced security, data, video, and voice services over industrial networks.
General Information
- Brand Name
- Cisco
- Manufacturer
- Cisco Systems, Inc
- Manufacturer Part Number
- IE-4000-4T4P4G-E
- Manufacturer Website Address
- http://www.cisco.com
- Product Model
- IE-4000-4T4P4G-E
- Product Name
- IE-4000-4T4P4G-E Layer 3 Switch
- Product Series
- 4000
- Product Type
- Layer 3 Switch
Interfaces/Ports
- Modular
- No
- Port/Expansion Slot Details
- 8 x Fast Ethernet Network
- Stack Port
- No
- Total Number of Network Ports
- 12
- Uplink Port
- Yes
Management & Protocols
- Manageable
- Yes
Media & Performance
- Ethernet Technology
- Gigabit Ethernet
- Media Type Supported
- Twisted Pair
- Network Technology
- 100Base-X
Miscellaneous
- Certifications & Standards
- TAA CompliantCEElectromagnetic Emissions:FCC 47 CFR Part 15 Class AEN 55022A Class AVCCI Class AAS/NZS CISPR 22 Class ACISPR 11 Class ACISPR 22 Class AICES 003 Class ACNS13438 Class AKN22Electromagnetic Immunity:EN55024CISPR 24AS/NZS CISPR 24KN24EN 61000-4-2 Electro Static DischargeEN 61000-4-3 Radiated RFEN 61000-4-4 Electromagnetic Fast TransientsEN 61000-4-5 SurgeEN 61000-4-6 Conducted RFEN 61000-4-8 Power Frequency Magnetic FieldEN 61000-4-9 Pulse Magnetic FieldEN 61000-4-11 AC Power VoltageEN 61000-4-18 Damped Oscillatory WaveEN-61000-4-29 DC Voltage DipsIndustry Standards:EN 61000-6-1 Light IndustrialEN 61000-6-2 IndustrialEN 61000-6-4 IndustrialEN 61326 Industrial ControlEN 61131-2 Programmable ControllersIEEE 1613 Electric Power Stations Communications NetworkingIEC 61850-3 Electric Substations Communications NetworkingEN50155 Railway - Electronic Equipment on Rolling Stock (EMC, ENV, Mech)EN50121-4 Railway - Signaling and Telecommunications ApparatusEN50121-3-2 Railway - Apparatus for Rolling StockODVA Industrial EtherNet/IPPROFINET conformance BIP30 (per EN60529)Information Technology Equipment:UL/CSA 60950-1EN 60950-1CB to IEC 60950-1 with all country deviationsNOM to NOM-019-SCFI (through partners and distributor)Industrial Floor (Control Equipment):UL 508CSA C22.2, No 142Hazardous Locations:ANSI/ISA 12.12.01 CSA C22.2 No 213IEC 60079-0, -15 IECEx test reportEN 60079-0, -15 ATEX certification (Class I Zone 2)Shock and Vibration:IEC 60068-2-27 (operational shock, 50G, 11ms, Half Sine)IEC 60068-2-27 (Non-Operational Shock, 65-80G, 9ms, Trapezoidal)IEC 60068-2-6, IEC 60068-2-64, EN 61373 (Operational Vibration)IEC 60068-2-6, IEC 60068-2-64, EN 61373 (Non-operational Vibration)Corrosion:ISO 9223: Corrosionclass C3-Mediumclass C4-HighEN 60068-2-52 (Salt Fog)EN 60068-2-60 (Flowing Mixed Gas)IEEE Standards:802.1D MAC Bridges, STP802.1p Layer2 COS prioritization802.1q VLAN802.1s Multiple Spanning-Trees802.1w Rapid Spanning-Tree802.1x Port Access Authentication802.1AB LLDP802.3ad Link Aggregation (LACP)802.3af Power over Ethernet provides up to 15.4W DC power to each end device802.3at Power over Ethernet provides up to 25.5W DC power to each end device802.3af Power over Ethernet802.3at Power over Ethernet Plus802.3ah 100BASE-X SMF/MMF only802.3x full duplex on 10BASE-T802.3 10BASE-T specification802.3u 100BASE-TX specification802.3ab 1000BASE-T specification802.3z 1000BASE-X specification 1588v2 PTP Precision Time Protocol
- Green Compliance Certificate/Authority
- RoHS
- Green Compliant
- Yes
Network & Communication
- Layer Supported
- 3
Physical Characteristics
- Depth
- 6.1"
- Form Factor
- Rail-mountable
- Height
- 5.1"
- Weight (Approximate)
- 6.35 lb
- Width
- 6.1"
Power Description
- Power Source
- Power Supply
- Redundant Power Supply
- Yes
