CISCO1801-M
by Cisco
10 Ports - Management Port - PoE Ports - 2 Slots - Fast Ethernet - ISDN/DSL - ADSL - 1U - Rack-mountable, Desktop, Wall Mountable
- Unspsc:
- 43222609
- Upc:
- 882658149900
- Description:
- The Cisco 1801 Integrated Services Router intelligently embed data, security, and wireless technology into a single, resilient system for fast, secure, scalable delivery of mission-critical business applications. The best-in-class Cisco 1801 architecture has been specifically designed to meet requirements of small to medium-sized businesses (SMBs), enterprise branch offices, and service provider-managed services applications for delivery of concurrent services at wire-speed performance. The integrated secure systems architecture of the Cisco 1801 delivers maximum business agility and investment protection.
Interfaces/Ports
- Number of Network (RJ-45) Ports
- 8
- Management Port
- Yes
- Number of Broadband (RJ-45) Ports
- 1
- Number of RJ-11 Ports
- 1
- Total Number of Ports
- 10
General Information
- Product Type
- Router
- Manufacturer Part Number
- CISCO1801-M
- Manufacturer Website Address
- http://www.cisco.com
- Manufacturer
- Cisco Systems, Inc
- Product Model
- 1801
- Product Name
- 1801 Integrated Services Router Annex M
- Product Series
- 1800
- Brand Name
- Cisco
I/O Expansions
- Number of Total Expansion Slots
- 2
Media & Performance
- Broadband Transmission Speed
- 8 Mbit/s
- Broadband Transmission Technology
- ADSL
- Broadband Transmission Standard
- G.dmt
- Carrier Supported
- ISDN/DSL
Memory
- Flash Memory
- 32 MB
- Standard Memory
- 128 MB
- Memory Technology
- DRAM
- Memory Card Supported
- CompactFlash
Miscellaneous
- Additional Information
- Cisco IOS IP broadbandSupported on 10/100 Ethernet switch ports with optional PoE kit
Network & Communication
- Network Technology
- ISDN BRI (S/T)
- Ethernet Technology
- Fast Ethernet
Physical Characteristics
- Weight (Approximate)
- 6.17 lb
- Form Factor
- Wall Mountable
- Height
- 1.8"
- Width
- 12.7"
- Depth
- 9.7"
- Compatible Rack Unit
- 1U
Power Description
- Input Voltage
- 220 V AC
- Power Source
- Power Supply
- PoE (RJ-45) Port
- Yes
Management & Protocols
- Security Features
- DES3DESAES 128AES 192AES 256Intrusion Prevention System (IPS)AutoSecureSite-to-Site VPNDynamic Multipoint VPN (DMVPN)SSL VPNNetwork Admission Control (NAC)
