WS-C2960CX-8PC-L
by Cisco
10 Ports - Manageable - 2 x Expansion Slots - 10/100/1000Base-T, 1000Base-X - Uplink Port - 2 x SFP Slots - 3 Layer Supported - Desktop, Rack-mountable, Rail-mountableLifetime Limited Warranty
- Unspsc:
- 43222612
- Upc:
- 882658753305
- Description:
- The Cisco Catalyst 3560-CX and 2960-CX Series Compact Switches help optimize network deployments. These Gigabit Ethernet (GbE) managed switches are ideal for high-speed data connectivity, Wi-Fi backhaul, and Power over Ethernet (PoE) connectivity in places where space is at a premium. With a single copper or fiber cable from the wiring closet, Catalyst compact switches enable IP connectivity for devices such as IP phones, wireless access points, surveillance cameras, PCs, and video endpoints.With their quiet, fan-less design and compact footprint, these switches offer flexible mounting options and open up a variety of network design and connectivity options. Use them in offices, classrooms, hotels, retail stores, and other enterprise and branch locations. The setup allows for shorter cable runs from the compact switches, allowing for flexibility in space redesign and growth as new devices join the network - this eliminating the need for expensive and inflexible cabling infrastructure.
General Information
- Brand Name
- Cisco
- Manufacturer
- Cisco Systems, Inc
- Manufacturer Part Number
- WS-C2960CX-8PC-L
- Manufacturer Website Address
- http://www.cisco.com
- Product Line
- Catalyst
- Product Model
- 2960CX-8PC-L
- Product Name
- 2960CX-8PC-L Layer 3 Switch
- Product Series
- 2960-CX
- Product Type
- Layer 3 Switch
I/O Expansions
- Expansion Slot Type
- SFP
- Number of SFP Slots
- 2
- Number of Total Expansion Slots
- 2
- Shared SFP Slot
- No
Interfaces/Ports
- Bypass
- No
- LRE Port
- No
- Management Port
- No
- Modular
- No
- Number of PoE+ (RJ-45) Ports
- 10
- Port/Expansion Slot Details
- 8 x Gigabit Ethernet Network
- Stack Port
- No
- Token Ring Port
- No
- Total Number of Network Ports
- 10
- Uplink Port
- Yes
- USB
- No
Management & Protocols
- Manageable
- Yes
- Management
- DHCPRMONVLANSNMP v1, 2c, 3TelnetCLIQoS
Media & Performance
- Ethernet Technology
- Gigabit Ethernet
- Media Type Supported
- Twisted Pair
- Network Technology
- 1000Base-X
Memory
- Flash Memory
- 128 MB
- Memory Technology
- DRAM
- Standard Memory
- 512 MB
Miscellaneous
- Certifications & Standards
- IEEE Standards:802.1D Spanning Tree Protocol802.1p CoS Prioritization802.1Q VLAN802.1s802.1w802.1x802.1AB (LLDP)802.3ad802.3af802.3ah(100BASE-X single/multimode fiber only)802.3x full duplex on 10BASE-T, 100BASE-TX, and 1000BASE-T ports802.3 10BASE-T specification802.3u 100BASE-TX specification802.3ab 1000BASE-T specification802.3z 1000BASE-X specificationSafety:UL 60950-1CAN/CSA 22.2 No. 60950-1EN 60950-1IEC 60950-1CE MarkingGB 4943IEC 60825Electromagnetic emissions certifications:FCC Part 15, CFR 47, Class A, North AmericaEN 55022 (CISPR22) and EN 55024 (CISPR24), CE marking, European UnionAS/NZS, Class A, CISPR22:2004 or EN55022, Australia and New ZealandVCCI Class A, V-3/2007.04, JapanKCC (Formerly MIC, GB17625.1-1998) Class A, KN24/KN22, KoreaANATEL, BrazilCCC, ChinaGOST, Russia
- Green Compliance Certificate/Authority
- RoHS-6
- Green Compliant
- Yes
Network & Communication
- Layer Supported
- 3
Physical Characteristics
- Depth
- 9.4"
- Form Factor
- Rail-mountable
- Height
- 1.8"
- Weight (Approximate)
- 5 lb
- Width
- 10.6"
Power Description
- Input Voltage
- 230 V AC
- PoE (RJ-45) Port
- Yes
- Power Source
- Power Supply
Reliability
- MTBF
- 569530 Hour
