CISCO2620
by Cisco
1 x AIM, 1 x Network Module - 1 x 10/100Base-TX LAN
- Unspsc:
- 43222609
- Upc:
- 638170291685
- Nsn:
- 7025014704564
- Description:
- The Cisco 2600 series is an award-winning family of modular multiservice access routers, providing flexible LAN and WAN configurations, multiple security options, voice/data integration, and a range of highperformance processors. This range offeatures make the Cisco 2600 family the ideal branch-office router for today's and tomorrow's customer requirements.
General Information
- Brand Name
- Cisco
- Manufacturer
- Cisco Systems, Inc
- Manufacturer Part Number
- CISCO2620
- Manufacturer Website Address
- http://www.cisco.com
- Product Model
- 2620
- Product Name
- 2620 Router
- Product Series
- 2600
- Product Type
- Router
I/O Expansions
- Expansion Slot Type
- WIC
- Number of Total Expansion Slots
- 4
Interfaces/Ports
- Management Port
- Yes
- Number of Network (RJ-45) Ports
- 1
- Total Number of Ports
- 1
Memory
- Flash Memory
- 8 MB
- Maximum Memory
- 64 MB
- Memory Technology
- DRAM
- Standard Memory
- 32 MB
Miscellaneous
- Additional Information
- The Cisco 2600 Series offers a comprehensive feature set ideal for solutions requiring the following support: Multiservice voice/data integrationVPN access with Firewall and Encryption optionsAnalog dial access servicesRouting with bandwidth managementInter-VLAN routingDelivery of high-speed business class DSL accessCost effective ATM accessIntegration of flexible routing and low density switching Minimum Cisco IOS Release:12.0(3)T or later and 12.1.1 mainline
- Certifications & Standards
- Safety: UL 60950:2000NOM019:1998EN 60950:1992+A1+A2+A3+A4 ACATS 001: 1993ACA AS3260:1997 Regulatory Compliance:FCC Class A and Canadian DOC Class AEN55022:1998, CISPR22:1997EN61000-3-2:1995EN61000-3-3:1995EN300386:2000EN55024/EN55082-1AS/NZS3548:199847-CFR-15:1997VCCI:V-3/2000VCCI Class ACNS 13438
Network & Communication
- Ethernet Technology
- Fast Ethernet
- Network Technology
- 10/100Base-TX
Physical Characteristics
- Compatible Rack Unit
- 1U
- Depth
- 11.8"
- Form Factor
- Wall Mountable
- Height
- 1.7"
- Weight (Approximate)
- 10.25 lb
- Width
- 17.5"
Power Description
- Input Voltage
- 220 V AC
