UCS-E140S-M2/K9
by Cisco
1 Processor Support - 8 GB Standard/16 GB DDR3 SDRAM Maximum RAM - Serial Attached SCSI (SAS) RAID Supported Controller - Gigabit Ethernet, Fast Ethernet - RAID Level: 0, 1
- Unspsc:
- 43211501
- Upc:
- 882658689147
- Description:
- These price-to-performance optimized single-socket blade servers balance simplicity, performance, reliability, and power efficiency and are well suited for applications and infrastructure services typically deployed in small and branch offices. By using the Cisco ISR G2 as the blade server chassis, customers can now deploy a single converged networking and computing platform designed specifically for remote- and branch-office infrastructure consolidation.
Controllers
- Controller Type
- Serial Attached SCSI (SAS)
- RAID Levels
- 0, 1
- RAID Supported
- Yes
General Information
- Brand Name
- Cisco
- Manufacturer
- Cisco Systems, Inc
- Manufacturer Part Number
- UCS-E140S-M2/K9
- Manufacturer Website Address
- http://www.cisco.com
- Product Model
- E140S
- Product Name
- UCS E140S Server
- Product Series
- E
- Product Type
- Server
I/O Expansions
- Number of Internal 2.5" Bays
- 2
- Number of Total Expansion Bays
- 2
Interfaces/Ports
- Network (RJ-45)
- Yes
- Number of USB 2.0 Ports
- 2
- Remote Management
- Yes
- Total Number of USB Ports
- 2
- VGA
- Yes
Memory
- Maximum Memory
- 16 GB
- Memory Card Reader
- Yes
- Memory Card Supported
- SD
- Memory Standard
- DDR3-1333/PC3-10600
- Memory Technology
- DDR3 SDRAM
- Number of Total Memory Slots
- 2
- Standard Memory
- 8 GB
Miscellaneous
- Certifications & Standards
- Safety: UL 60950-1 Second Edition CAN/CSA-C22.2 No. 60950-1 IEC 60950-1 Second Edition EN 60950-1 Second Edition AS/NZS 60950-1 EMC: Emissions: 47CFR Part 15 (CFR 47) Class A AS/NZS CISPR22 Class A CISPR2 2 Class A EN55022 Class A ICES003 Class A VCCI V-3 Class I EN61000-3-2 EN61000-3-3 EN300386 Class A CNS13438, Class A EMC: Immunity: EN55024 CISPR24 EN300386 EN50082-1 Part 1 EN 61000 6-1 Certifications
- Compatibility
- Operating Systems: Microsoft Windows Server Red Hat Enterprise Linux (RHEL) SUSE Linux Oracle Enterprise Linux Hypervisors: Microsoft Hyper-V VMware vSphere Citrix XenServer
Network & Communication
- Ethernet Technology
- Gigabit Ethernet
Physical Characteristics
- Depth
- 7.5"
- Form Factor
- Blade
- Height
- 1.6"
- Weight (Approximate)
- 2.50 lb
- Width
- 7.4"
Processor & Chipset
- 64-bit Processing
- Yes
- Cache
- 6 MB
- Hyper-Threading
- Yes
- Number of Processors Installed
- 1
- Number of Processors Supported
- 1
- Processor Core
- Quad-core (4 Core)
- Processor Manufacturer
- Intel
- Processor Model
- E3-1105C
- Processor Speed
- 1 GHz
- Processor Type
- Xeon
- vPro Technology
- No
Software
- Operating System
- No
Storage
- Number of Hard Drives
- No
