Conditions Available
Warranties Available
UCS-E140S-M1/K9
by Cisco
1 Processor Support - 8 GB Standard/16 GB DDR3 SDRAM Maximum RAM - Serial Attached SCSI (SAS) RAID Supported Controller - Gigabit Ethernet, Fast Ethernet - RAID Level: 0, 1
- Unspsc:
- 43211501
- Upc:
- 882658510397
- Description:
- Data Center-Class Blade Servers for the Branch Simplify your branch office infrastructure with a converged networking, computing, and virtualization ready platform designed to host multiple Cisco and third-party infrastructure services and mission-critical business applications.
Controllers
- Controller Type
- Serial Attached SCSI (SAS)
- RAID Levels
- 0, 1
- RAID Supported
- Yes
General Information
- Brand Name
- Cisco
- Manufacturer
- Cisco Systems, Inc
- Manufacturer Part Number
- UCS-E140S-M1/K9
- Manufacturer Website Address
- http://www.cisco.com
- Product Model
- E140S
- Product Name
- UCS E140S Server
- Product Series
- E
- Product Type
- Server
I/O Expansions
- Number of Internal 2.5" Bays
- 2
- Number of Total Expansion Bays
- 2
Interfaces/Ports
- Network (RJ-45)
- Yes
- Number of USB 2.0 Ports
- 2
- Remote Management
- Yes
- Total Number of USB Ports
- 2
- VGA
- Yes
Memory
- Maximum Memory
- 16 GB
- Memory Card Reader
- Yes
- Memory Card Supported
- SD
- Memory Standard
- DDR3-1333/PC3-10600
- Memory Technology
- DDR3 SDRAM
- Number of Total Memory Slots
- 2
- Standard Memory
- 8 GB
Miscellaneous
- Certifications & Standards
- Safety: UL 60950-1 Second Edition CAN/CSA-C22.2 No. 60950-1 IEC 60950-1 Second Edition EN 60950-1 Second Edition AS/NZS 60950-1 EMC: Emissions: 47CFR Part 15 (CFR 47) Class A AS/NZS CISPR22 Class A CISPR2 2 Class A EN55022 Class A ICES003 Class A VCCI V-3 Class I EN61000-3-2 EN61000-3-3 EN300386 Class A CNS13438, Class A EMC: Immunity: EN55024 CISPR24 EN300386 EN50082-1 Part 1 EN 61000 6-1
- Compatibility
- Operating Systems: Microsoft Windows Server Red Hat Enterprise Linux (RHEL) SUSE Linux Oracle Enterprise Linux Hypervisors: Microsoft Hyper-V VMware vSphere Citrix XenServer
Network & Communication
- Ethernet Technology
- Gigabit Ethernet
Physical Characteristics
- Depth
- 7.5"
- Form Factor
- Blade
- Height
- 1.6"
- Weight (Approximate)
- 2.50 lb
- Width
- 7.4"
Processor & Chipset
- 64-bit Processing
- Yes
- Cache
- 6 MB
- Hyper-Threading
- Yes
- Number of Processors Installed
- 1
- Number of Processors Supported
- 1
- Processor Core
- Quad-core (4 Core)
- Processor Manufacturer
- Intel
- Processor Model
- E3-1105C
- Processor Speed
- 1 GHz
- Processor Type
- Xeon
Software
- Operating System
- No
Storage
- Number of Hard Drives
- No
HP 736968-001
Refurb HP ProLiant ML350p Gen8 E5-2650v2 2P 16GB-R P420i/2GB FBWC 8 SFF 750W RPS Server
