Conditions Available
Warranties Available
ICX7250-24P
by Brocade
24 Ports - Manageable - Stack Port - 8 x Expansion Slots - 10/100/1000Base-TX, 10GBase-X - Uplink Port - Modular - 24, 8 x Network, Expansion Slot - Optical Fiber, Twisted Pair - Gigabit Ethernet, 10 Gigabit Ethernet - 8 x SFP+ Slots - 3 Layer Supported - Power Supply - 1U High - Rack-mountableLifetime Limited Warranty
- Unspsc:
- 43222612
- Description:
- Entry-Level, Enterprise-Class Stackable Switch with Future-Proof Expandability The Brocade® ICX® 7250 Switch delivers the performance, flexibility, and scalability required for enterprise Gigabit Ethernet (GbE) access deployment. It raises the bar with up to 8×10 GbE ports for uplinks or stacking and market-leading stacking density with up to 12 switches (576×1 GbE) per stack. In addition, the Brocade ICX 7250 combines enterprise-class features, manageability, performance, and reliability with the flexibility, cost-effectiveness, and "pay as you grow" scalability of a stackable solution.
Interfaces/Ports
- Modular
- Yes
- Uplink Port
- Yes
- Stack Port
- Yes
- Total Number of Network Ports
- 24
- Port/Expansion Slot Details
- 8 x 10 Gigabit Ethernet Expansion Slot
General Information
- Product Type
- Layer 3 Switch
- Manufacturer Part Number
- ICX7250-24P
- Manufacturer Website Address
- http://www.brocade.com
- Manufacturer
- Brocade Communications Systems, Inc
- Product Model
- ICX 7250-24P
- Product Name
- ICX 7250 Switch
- Product Series
- ICX 7250
- Brand Name
- Brocade
I/O Expansions
- Expansion Slot Type
- SFP+
- Number of Total Expansion Slots
- 8
- Number of SFP+ Slots
- 8
Media & Performance
- Network Technology
- 10GBase-X
- Ethernet Technology
- 10 Gigabit Ethernet
- Media Type Supported
- Twisted Pair
Miscellaneous
- Package Contents
- ICX 7250 Switch Power Cord 2 x Post Rack Mounting Brackets USB Serial Console Cable
- Green Compliant
- Yes
- Green Compliance Certificate/Authority
- WEEE
Network & Communication
- Layer Supported
- 3
Physical Characteristics
- Weight (Approximate)
- 10.43 lb
- Form Factor
- Rack-mountable
- Height
- 1.7"
- Width
- 17.3"
- Depth
- 11"
- Compatible Rack Unit
- 1U
Power Description
- Power Source
- Power Supply
Management & Protocols
- Manageable
- Yes
Additional Product Specifications
- Full Product Specifications
- Click to view
