Conditions Available
Warranties Available
S3500-48P
by Aruba Networks
48 Ports - Manageable - 1 x Expansion Slots - 10/100/1000Base-T - Modular - 3 Layer Supported - Redundant Power Supply - 1U High - Desktop, Rack-mountableLifetime Limited Warranty
- Unspsc:
- 43222612
- Description:
- For high-density, high-availability wiring closets The S3500 Mobility Access Switch from Aruba Networks® extends role-based user access, security and operational simplicity to wired networks. A vital part of the Aruba Mobile Virtual Enterprise™ (MOVE) architecture, the S3500 delivers secure, virtualized access services to users, regardless of their location, access method, device or applications.The S3500 is available in five models, with 24 or 48 10/100/1000BASE-T ports with optional power-over Ethernet (PoE) and 24 1000BASE-XSFP ports.
General Information
- Brand Name
- Aruba Networks
- Manufacturer
- Aruba Networks, Inc
- Manufacturer Part Number
- S3500-48P
- Manufacturer Website Address
- http://www.arubanetworks.com
- Product Model
- S3500-48P
- Product Name
- S3500-48P Mobility Access Switch
- Product Series
- S3500
- Product Type
- Layer 3 Switch
I/O Expansions
- Number of Total Expansion Slots
- 1
Interfaces/Ports
- Bypass
- No
- LRE Port
- No
- Management Port
- Yes
- Modular
- Yes
- Number of PoE+ (RJ-45) Ports
- 48
- Port/Expansion Slot Details
- 48 x Gigabit Ethernet Network
- Stack Port
- No
- Token Ring Port
- No
- Total Number of Network Ports
- 48
- Uplink Port
- No
- USB
- Yes
Management & Protocols
- Manageable
- Yes
- Management
- Web-based Management CLI SNMP v1, v2c, v3 RMON VLAN QoS DHCP
Media & Performance
- Ethernet Technology
- Gigabit Ethernet
- Media Type Supported
- Twisted Pair
- Network Technology
- 10/100/1000Base-T
Miscellaneous
- Certifications & Standards
- IEEE Standards: 802.3af 802.3at 802.1AB 802.1Q 802.1D 802.1w 802.1s Safety: UL-UL60950-1 C-UL to CAN/CSA 22.2 No.60950-1 TUV/GS to EN 60950-1 CB-IEC60950-1 EMC: FCC 47CFR Part 15, Class A EN 55022 Class A ICES-003 Class A VCCI Class A AS/NZS CISPR 22 Class A CISPR 22 Class A EN 55024
- Green Compliance Certificate/Authority
- RoHS-5
- Green Compliant
- Yes
- Package Contents
- S3500-48P Ethernet Switch 600-watt AC Power Supply
Network & Communication
- Layer Supported
- 3
Physical Characteristics
- Compatible Rack Unit
- 1U
- Depth
- 17.5"
- Form Factor
- Rack-mountable
- Height
- 1.8"
- Weight (Approximate)
- 17.50 lb
- Width
- 17.5"
Power Description
- Input Voltage
- 220 V AC
- PoE (RJ-45) Port
- No
- Power Source
- Power Supply
- Redundant Power Supply
- Yes
