AP-103H
by Aruba Networks
2 x Antenna(s) - 2 x Internal Antenna(s) - 3 x Network (RJ-45) - Wall Mountable
- Unspsc:
- 43222631
- Description:
- Multifunctional and affordable, the dual-radio AP-103H hospitality access point (AP) maximizes mobile device performance in moderately dense Wi-Fi environments while minimizing interference from cellular networks. The AP-103H installs in minutes and easily mounts to an electrical or data wall box. It uses the existing structured cabling system to provide secure wired and Wi-Fi network access in dormitories, classrooms, hotels, medical clinics and multitenant environments.The compact and cost-effective AP-103H delivers wireless data rates up to 300 Mbps per radio employing 802.11n technology with two spatial MIMO streams. This 2×2:2 AP features dedicated 2.4-GHz and 5-GHz radios and integrated omni-directional antennas.
Interfaces/Ports
- Ethernet Port
- Yes
- Fast Ethernet Port
- Yes
- Gigabit Ethernet Port
- Yes
- 10Gigabit Ethernet Port
- No
- USB
- No
- HDMI
- No
- VGA
- No
- Number of Network (RJ-45) Ports
- 3
- Audio Line Out
- No
- Network (RJ-11)
- No
- Powerline
- No
- Management Port
- Yes
General Information
- Product Type
- Wireless Access Point
- Manufacturer Part Number
- AP-103H
- Manufacturer Website Address
- http://www.arubanetworks.com
- Manufacturer
- Aruba Networks, Inc
- Product Model
- AP-103H
- Product Name
- AP-103H Hospitality Access Point
- Brand Name
- Aruba Networks
Miscellaneous
- Package Contents
- AP-103H Hospitality Access Point Single-Gang Universal Mount Plate 2 x Mount Screws (#6-32 x 1" Machine Screw) Tool for Secure Mount Mechanism Installation Guide
- Certifications & Standards
- FCC/Industry of Canada CE Marked R&TTE Directive 1995/5/EC Low Voltage Directive 72/23/EEC EN 300 328 EN 301 489 EN 301 893 UL/IEC/EN 60950 EN 60601-1-1 EN 60601-1-2 CB Scheme Safety cTUVus IEEE Standards: 802.11a 802.11b 802.11g 802.11n 802.3af 802.3at 802.3az
Physical Characteristics
- Weight (Approximate)
- 9.17 oz
- Form Factor
- Wall Mountable
- Height
- 5.5"
- Width
- 3.4"
- Depth
- 1.2"
Power Description
- Input Voltage
- 12 V DC
- Power Source
- PoE
Management & Protocols
- Management
- Adaptive Radio Management
Technical Information
- Features
- Cable Lock Slot
- Wireless Transmission Speed
- 300 Mbit/s
- Wireless LAN Standard
- IEEE 802.11n
- ISM Band
- Yes
- UNII Band
- Yes
- ISM Minimum Frequency
- 2.40 GHz
- ISM Maximum Frequency
- 2.48 GHz
- UNII Minimum Frequency
- 5.15 GHz
- UNII Maximum Frequency
- 5.85 GHz
- Antenna Gain
- 3.6 dBi
- Antenna Type
- Omnidirectional Antenna
- Total Number of Antennas
- 2
- Number of Internal Antennas
- 2
