SRT5KXLI
by Apc
5000 VA/4500 W - 4 Minute - Tower - 4 Minute - Surge, Spike, Lightning
- Unspsc:
- 39121011
- Description:
- A versatile UPS developed for the harshest power conditions in the world. Smart-UPS On-Line provides high density, true double-conversion on-line power protection for servers, voice / data networks, medical labs, and light industrial applications. Capable of supporting loads from 1 to 20kVA in a rack/tower convertible form, the Smart-UPS On-Line is available from 2U to 12U. Recent family extensions at 15 and 20kVA enable support of power hungry blade servers or heavily loaded equipment racks. When business-critical systems require runtime in hours, not minutes, Smart-UPS On-Line can be configured with matching battery packs to comply with aggressive runtime demands. The included PowerChute management software provides unattended graceful shutdown of network operating systems. All models 5kVA and above include an integrated Network Management Card for remote management (optional on models below 5 kVA). The Smart-UPS On-Line family provides customers with a reliable source of uninterruptible power even in demanding power environments, including very wide input voltage window, extremely tight output voltage regulation, frequency regulation, internal bypass, and input power factor correction.
Battery Information
- Battery Chemistry
- Sealed Lead Acid
- Hot Swappable
- Yes
- Maximum Battery Recharge Time
- 3 Hour
- Number of Batteries
- 1
- Backup/Run Time (Half Load)
- 12 Minute
- Backup/Run Time (Full Load)
- 4 Minute
- Battery Characteristics
- Maintenance-free, Sealed, Spill-proof
Controls/Indicators
- Status Indicators
- LED Indicators
Interfaces/Ports
- USB
- Yes
- Network (RJ-45)
- Yes
- Total Number of Expansion Slots
- 1
Environmental Conditions
- Sound Emission
- 55 dB(A)
- Temperature
- 104°F (40°C)
- Thermal Dissipation
- 931 BTU/h
General Information
- Product Type
- Dual Conversion Online UPS
- Manufacturer Part Number
- SRT5KXLI
- Manufacturer Website Address
- http://www.apc.com
- Manufacturer
- American Power Conversion Corp
- Product Name
- Smart-UPS SRT 5000VA 230V
- Product Line
- Smart-UPS On-Line
- Brand Name
- APC
Management
- Alarm
- Battery Failure
Physical Characteristics
- Weight (Approximate)
- 120.26 lb
- Color
- Black
- Form Factor
- Tower
- Height
- 17"
- Width
- 5.1"
- Depth
- 28.3"
Power Description
- Circuit Breaker
- Yes
- Output Voltage
- 230 V AC
- Waveform Type
- Sine Wave
- Load Capacity (VA)
- 5000 VA
- Load Capacity (Watt)
- 4500 W
Technical Information
- Bypass Switch
- Automatic & Manual
- Emergency Power OFF
- Yes
- Protection Type
- Lightning
