AP7750
by Apc
1440VA
- Unspsc:
- 39121100
- Nsn:
- 6110015558792
- Description:
- APC Rack Automatic Transfer Switch (ATS), also known as the Redundant Switch, is a high availability switch. The Rack ATS is designed to supply power to the connected load from a primary AC source. If that primary source becomes unavailable for whatever reason, the Rack ATS will automatically begin sourcing power from the secondary source. The transfer time from one source to the other is seamless to the connected equipment. The Networked units have built-in network connectivity, which allows for remote management via Web, SNMP, or Telnet interfaces.
Environmental Conditions
- Altitude
- 0 ft to 50000 ft Storage
- Humidity
- 0% to 95% Relative Humidity Storage
- Temperature
- -13°F (-25°C) to 149°F (65°C) Storage
General Information
- Product Type
- Automatic Transfer Switch
- Manufacturer Part Number
- AP7750
- Manufacturer Website Address
- http://www.apc.com
- Manufacturer
- American Power Conversion Corp
- Product Name
- 1U Rack 12A Automatic Transfer Switch
- Brand Name
- APC
Miscellaneous
- Additional Information
- Flash UpgradeableInformation DisplaysQuick Transfer RateRemote Management CapabilitiesStandard Warranty: 2 Year Repair/Replace
- Package Contents
- Rack Mounting BracketsUser Manual
- Certifications & Standards
- cULFCC Part 15 Class AULVCCI
Physical Characteristics
- Weight (Approximate)
- 8.60 lb
- Form Factor
- 1U Rack-mountable
- Power Cord/Cable
- 8 ft Input
- Height
- 1.8"
- Width
- 17"
- Depth
- 9"
Power Description
- Input Voltage
- 110 V AC
- Output Voltage
- 120 V AC
- Current
- 12 A Line Current Per Phase
- Frequency
- 60 Hz
- Load Capacity
- 1.44 kVA
- Input Voltage Range
- 100 V AC to 125 V AC
Technical Information
- Receptacles
- 8 x NEMA 5-15R
- Plug/Connector Type
- NEMA 5-15P
