1200740E1
by Adtran
2 x FXS, 2 x FXO, 1 x 10/100Base-TX WAN, 24 x 10/100Base-TX PoE LAN, 2 x 10/100/1000Base-T Uplink
- Unspsc:
- 43222609
- Upc:
- 95753489448
- Description:
- The NetVanta 6355 Multiservice Access Gateway is a unique, all in one solution for Hosted VoIP PBX services, Internet access, and business connectivity. This powerful platform combines the voice functionality of Adtran's industry leading Total Access 900e Multiservice Access Device and the widely deployed NetVanta Power over Ethernet (PoE) Switch-Router into a compact 1U chassis. This all-in-one product includes a robust SIP-Gateway, a full-featured IP router, stateful inspection firewall, VPN, 24-port powered (802.3af ) Fast Ethernet switch with Gigabit uplinks, and two expansion slots for Network and Voice Interface Modules (NIM/VIMs).
Interfaces/Ports
- Number of Network (RJ-45) Ports
- 24
- Management Port
- Yes
- Number of Broadband (RJ-45) Ports
- 1
- Number of RJ-11 Ports
- 2
- Total Number of Ports
- 29
General Information
- Product Type
- Router
- Manufacturer Part Number
- 1200740E1
- Manufacturer Website Address
- http://www.adtran.com
- Manufacturer
- Adtran
- Product Model
- 6355
- Product Name
- NetVanta 6355 Multiservice Access Gateway
- Product Line
- NetVanta
- Brand Name
- Adtran
I/O Expansions
- Expansion Slot Type
- SFP (mini-GBIC)
- Number of Total Expansion Slots
- 5
Memory
- Flash Memory
- 32 MB
- Standard Memory
- 128 MB
- Memory Technology
- DRAM
- Memory Card Supported
- CompactFlash
Miscellaneous
- Additional Information
- Packet-based Voice Resources:CODECsG.711-64k PCMG.729a-8k CS-ACELPG.168 Echo Cancellation64ms Echo-tail LengthSupports up to 16 Simultaneous Channelss
Network & Communication
- Network Technology
- 10/100Base-TX
- Ethernet Technology
- Fast Ethernet
- VoIP Supported
- Yes
Physical Characteristics
- Weight (Approximate)
- 11 lb
- Form Factor
- Rack-mountable
- Height
- 1.8"
- Width
- 17.3"
- Depth
- 12.8"
- Compatible Rack Unit
- 1U
Power Description
- Input Voltage
- 220 V AC
- Power Source
- Power Supply
Management & Protocols
- Security Features
- PAP and CHAPStateful Inspection FirewallDenial of Service (DoS) ProtectionAccess Control Lists (ACLs)Application Level Gateways (ALGs)Packet FilteringVirtual Private Network (VPN):IPSec Mode: TunnelEncryption: DES, 3DES, and AESNumber of Tunnels: Up to tenNetwork Address Translation:Basic NAT (1:1), NAPT (Many:1), and Port TranslationNAT Compatible SIP ALGSecure Management:Multilevel Access ControlTACACS+RADIUS AAASSH CLI and SSL GUINetwork Access Control:Port Authentication (802.1x)MAC-based Port Security
