Conditions Available
Warranties Available
1202860L1
by Adtran
1 x 10/100Base-TX LAN
- Unspsc:
- 43222609
- Nsn:
- 7025015438894
- Description:
- The NetVanta 3000 Series of modular access routers are designed for cost-effective Internet access, corporate Frame Relay, point-to-point connectivity, and Virtual Private Networking (VPN). The NetVanta 3200 is a single-slot, standalone unit in a plastic housing. A single slot within any of the NetVanta 3000 Series will house a variety of NIMs and DIMs, which include a 56/64K, T1/FT1, T1/FT1 with DSX-1, or a Serial interface. For dial backup, an Analog Modem or an ISDN BRI DIM is available for preventing down time by dialing around a failed circuit to any PPP compliant device. The versatile hardware platforms of the NetVanta 3200 is further complemented with the ADTRAN Operating System (OS). The ADTRAN OS allows for the support of static and default routes, and allows for fast, accurate network convergence using routing protocols such as OSPF and RIP. In addition, the ADTRAN OS terminates Frame Relay and PPP WAN protocols.
Interfaces/Ports
- Number of Network (RJ-45) Ports
- 1
- Management Port
- Yes
- Total Number of Ports
- 1
General Information
- Product Type
- Router
- Manufacturer Part Number
- 1202860L1
- Manufacturer Website Address
- http://www.adtran.com
- Manufacturer
- Adtran
- Product Model
- 3200
- Product Name
- NetVanta 3200 Access Router
- Product Line
- NetVanta
- Product Series
- 3000
- Brand Name
- Adtran
I/O Expansions
- Expansion Slot Type
- NIM/DIM
- Number of Total Expansion Slots
- 1
Memory
- Flash Memory
- 8 MB
- Standard Memory
- 32 MB
Miscellaneous
- Additional Information
- Modular Network Interface Module (NIM) offering flexibilityModular Dial Backup Interface Module (DIM) guaranteeing bandwidthStateful inspection firewall for network securityQuality of Service (QoS) for delay sensitive traffic like VoIPOptional DSX-1 interface supplies TDM voice transportComprehensive PPP dial backup scheme prevents network downtimeVLAN Trunking for routing between VLANsVPN for secure corporate connectivity across the InternetBuilt-in DSU/CSU for circuit protectionThe firewall can identify and protect against common Denial of Service (DoS) attacks like TCP syn flooding, IP spoofing, ICMP redirect, ping-of-death, and IP reassembly problems.Quality of Service (QoS) is also supported using DiffServ aware Weighted Fair Queuing allowing the NetVanta 3200 to guarantee quality service for delay sensitive traffic like VoIP or video.Application Level Gateways (ALGs)Multiprotocol Over Frame RelayLMI types: LMI, ANSI (Annex D), CCITT (Annex A) and StaticField upgradable, remotely configurableDiffie Hellman Group SupportGroup 1: MODP 768Group 2: MODP 1024Authentication Mechanisms:XAUTHDigital certificatesPreshared keysIKE Modes:MainAggressive
- Certifications & Standards
- 802.1QRFC 1490CULICES-003Agency Approvals:FCC Part 68Industry Canada CS03UL & Canadian UL (CUL), IEC/EN, CSACE Mark
Network & Communication
- Network Technology
- 10/100Base-TX
- Ethernet Technology
- Fast Ethernet
Physical Characteristics
- Weight (Approximate)
- 2 lb
- Form Factor
- Desktop
- Height
- 1.6"
- Width
- 9"
- Depth
- 6.4"
Power Description
- Input Voltage
- 220 V AC
- Power Source
- AC Adapter
