Cisco 48 Ports Manageable 2 X Expansion Slots 10 100 1000base T 48 2 X Network Expansion Slot Twisted Pair Gigabit Ethernet 10 Gigabit Ethernet 2 X Sfp Slots 2 Layer Supported Power Supply Redundant Power Supply 1u High Rack Mountable Desktoplifetime Limited Warranty Wsc2960x48fpdl
Recycle
Conditions Available
Lock
Warranties Available

WS-C2960X-48FPD-L
by Cisco
48 Ports - Manageable - 2 x Expansion Slots - 10/100/1000Base-T - 48, 2 x Network, Expansion Slot - Twisted Pair - Gigabit Ethernet, 10 Gigabit Ethernet - 2 x SFP+ Slots - 2 Layer Supported - Power Supply - Redundant Power Supply - 1U High - Rack-mountable, DesktopLifetime Limited Warranty


Unspsc:
43222612
Upc:
804891030852
Description:
Catalyst 2960-X series Software FeaturesAll Catalyst 2960-X Series Switches use a single Universal Cisco IOS Software Image for all SKUs. Depending on the switch model, the Cisco IOS image automatically configures either the LAN Lite, LAN Base, or IP Lite feature set.LAN Lite models have reduced functionality and scalability for small deployments with basic requirements. Cisco Catalyst 2960-X Family of Switches are available with the LAN Base and LAN Lite feature sets and Catalyst 2960-XR Family of switches are available IP Lite feature sets.Note that each switch model is tied to a specific feature level; LAN Lite cannot be upgraded to LAN Base and LAN Base cannot be upgraded to IP Lite.
General Information
Brand Name
Cisco
Manufacturer
Cisco Systems, Inc
Manufacturer Part Number
WS-C2960X-48FPD-L
Manufacturer Website Address
http://www.cisco.com
Product Line
Catalyst
Product Model
2960X-48FPD-L
Product Name
Catalyst 2960X-48FPD-L Ethernet Switch
Product Series
2960-X
Product Type
Ethernet Switch
I/O Expansions
Expansion Slot Type
SFP+
Number of SFP+ Slots
2
Number of Total Expansion Slots
2
Interfaces/Ports
Bypass
No
LRE Port
No
Management Port
Yes
Modular
No
Number of PoE (RJ-45) Ports
48
Port/Expansion Slot Details
48 x Gigabit Ethernet Network
Token Ring Port
No
Total Number of Network Ports
48
USB
Yes
Management & Protocols
Manageable
Yes
Management
Web-based ManagementVLANQoSSyslogTelnetRMON I, IISNMP v1, v2c, v3DHCPCLI
Media & Performance
Ethernet Technology
Gigabit Ethernet
Media Type Supported
Twisted Pair
Network Technology
10/100/1000Base-T
Twisted Pair Cable Standard
Category 5
Memory
Flash Memory
128 MB
Memory Technology
DRAM
Standard Memory
512 MB
Miscellaneous
Certifications & Standards
IEEE Standards:802.1D802.1p802.1Q802.1s802.1w802.1X802.1ab802.3ad802.3af802.3at802.3ah802.3x802.3802.3u802.3ab802.3z802.3az802.1ae802.3ae802.1axSafety:UL 60950-1 Second EditionCAN/CSA-C22.2 No. 60950-1 Second EditionEN 60950-1 Second EditionIEC 60950-1 Second EditionAS/NZS 60950-1EMC:47CFR Part 15 (CFR 47) Class AAS/NZS CISPR22 Class ACISPR22 Class AEN55022 Class AICES003 Class AVCCI Class AEN61000-3-2EN61000-3-3KN22 Class ACNS13438 Class AEN55024CISPR24EN300386KN24
Green Compliance Certificate/Authority
RoHS
Green Compliant
Yes
Network & Communication
Layer Supported
2
Physical Characteristics
Compatible Rack Unit
1U
Depth
14.5"
Form Factor
Rack-mountable
Height
1.8"
Weight (Approximate)
12.90 lb
Width
17.5"
Power Description
Input Voltage
220 V AC
PoE (RJ-45) Port
Yes
Power Source
Power Supply
Redundant Power Supply
Yes
Reliability
MTBF
233370 Hour
